DigiTech Ventura Vibe

The Ventura Vibe Rotary/Vibrato pedal from DigiTech will twist your equilibrium adding spinning, swaying movement to your guitar playing. It delivers both vintage and modern sounds with three rotary/vibrato effect types. Each can be uniquely contoured to accentuate high frequencies and driven to distort via the Ventura Vibe's stacked Tone and Drive controls. The versatility of these controls along with independent Speed, Depth and Mix controls allow you to dial up anything from mild amplitude and frequency modulation to a full on case of vertigo. Additionally, the Ventura Vibe's foot-switchable speed function allows you to ramp between slow and fast speed on the fly!

The Ventura Vibe's stellar rotary and vibrato effects are complimented by stereo inputs and outputs for routing flexibility, constant high voltage rails, a bicolor status LED indicator and true bypass circuitry. With its compact size, vacuum-style footswitch and striking graphics the Ventura Vibe furthers DigiTech's evolution in pedal design. We've put years of experience into every detail of its mechanical and sonic blueprint.

The Ventura Vibe uses a 9V DC power supply to easily integrate into your existing pedalboard.

Specifications
Input- Separate Left and Right ¼" Unbalanced (Tip-Sleeve)
Input Impedance- Effect on: >1 M (stereo), >500 k (mono); Effect off: True hardwire bypass
Output- Separate Left and Right ¼" Unbalanced (Tip-Sleeve)
Output Impedance- Effect on: 1 k; Effect off: True hardwire bypass
Controls- Speed, Rotary/Vibrato Type, Depth, Mix, Tone, Drive, Effect On/Off
Switches- Soft Click, Vacuum Style Footswitch; Effect Type Toggle Switch
Power Requirements- 9 VDC external power supply (required)
Power Consumption- 675 mW (< 75 mA @ 9 VDC)
Current Draw- 75 mA (typical at 9 VDC)
Power Supply- (Optional)Â Model PS0913DC-01 (US, JA, EU); PS0913DC-02 (AU, UK)
Power Supply Output- 9 VDC 1.3 A
Dimensions- 4.40 (L) x 2.65 (W) x 2.0 (H); 11.18cm (L) x 6.73cm (W) x 5.08cm (H)
Weight- 1 lb; 0.453 kg
