Recommended for professional bass guitar applications in a sealed or vented enclosure. Works well in single or multi-driver designs. This driver is at home in small sealed enclosures and works well in Pro Audio and Home Hi-Fi applications.

SPECIFICATION

Nominal Basket Diameter 10", 254 mm

Nominal Impedance* 8 Ω

Power Rating*

• Program Power 400 W
• Watts 200 W

Resonance 35 Hz

Usable Frequency Range 40 Hz - 2 kHz

Sensitivity* 91.8 dB

Magnet Weight 38 oz.

Gap Height 0.312", 7.9 mm

Voice Coil Diameter 2", 51 mm

THIELE & SMALL PARAMETERS

Resonant Frequency (fs) 35 Hz

DC Resistance (Re) 5.59 Ω

Coil Inductance (Le) 0.83m H

Mechanical Q (Qms) 5.36

Electromagnetic Q (Qes) 0.47

Total Q (Qts) 0.43

Compliance Equivalent Volume (Vas) 91.2 liters / 3.22 cu.ft.

Peak Diaphragm Displacement Volume (Vd) 207.4 cc

Mechanical Compliance of Suspension (Cms) 0.54 mm/N

BL Product (BL) 10 T-M

Diaphragm Mass Inc. Airload (MMs) 38 grams

Efficiency Bandwidth Product (EBP) 75

Maximum Linear Excursion (Xmax) 6.2 mm

Surface Area of Cone (Sd) 334.5 cm2

Maximum Mechanical Limit (Xlim) 10 mm

MOUNTING INFORMATION

Recommended Enclosure Volume

Sealed Acceptable

Vented Acceptable

Driver Volume Displaced 0.041 cu.ft. / 1.17 liters

Overall Diameter 10.08", 256 mm

Baffle Hole Diameter 9.18", 233.2 mm

Front Sealing Gasket Yes

Rear Sealing Gasket Yes

Mounting Holes Diameter 0.25", 6.4mm

Mounting Holes B.C.D. 9.66", 245.4mm

Depth 4.25", 108 mm

Net Weight 8.9 lbs, 4.04 kg

Shipping Weight 9.1 lbs, 4.13 kgs

MATERIALS OF CONSTRUCTION

Coil Construction Copper voice coil

Coil Former Polyimide former

Magnet Composition Ferrite magnet

Core Details Non-vented core

Basket Materials Pressed steel basket

Cone Composition Paper cone

Cone Edge Composition Cloth cone edge

Dust Cap Composition Zurette dust cap
