Upgrade your Jazzmaster-style guitar with a professionally wired Carparelli offset electronics package, now available pre-installed on your choice of Jazzmaster pickguard.
This is the perfect option for players who want the convenience of a clean, drop-in-ready wiring assembly without having to mount the components, shield the guard, solder the controls, or figure out the Jazzmaster rhythm/lead circuit layout from scratch.
Choose your pickguard colour, and Carparelli Guitars will professionally install and wire the complete Jazzmaster electronics kit directly onto the guard before shipping.
Please note: pickups are not included.
This is a loaded pickguard wiring kit, not a fully loaded pickup assembly.
Why Choose the Loaded Pickguard Option?
Jazzmaster wiring is one of the more involved offset circuits, with separate lead and rhythm controls, roller pots, slider switch, toggle switch, output jack, shielding, and multiple wiring runs. Having the kit professionally installed on the pickguard gives you a cleaner starting point and saves you time at the bench.
Instead of receiving loose parts and doing the full layout yourself, you receive the pickguard already prepared with the wiring harness installed and organized. Simply install your pickups, connect the pickup leads, mount the guard, and complete your final setup.
Includes
The Carparelli Jazzmaster wiring kit includes:
- USA-made vintage-style cloth wire
- 1 x Alpha 1 Meg split-shaft audio pot
- 1 x Alpha 1 Meg split-shaft linear pot
- 1 x Alpha 1 Meg solid-shaft linear roller pot
- 1 x Alpha 50K solid-shaft linear roller pot
- 1 x Brio right-angle toggle switch
- 1 x Brio on/on slider switch
- 1 x Pure Tone output jack
- 1 x Orange Drop capacitor
- 1 x Emerson Paper-in-Oil capacitor
- Mounting bracket for roller controls
- 2 x metal roller knobs
- 2 x spring-loaded sponge pickup raisers
- Professional installation onto selected pickguard
- Copper shielding applied where appropriate
- Clean wire routing and solder work
- Ready for customer-supplied pickups
Pickguard Choice
...
Select from available Carparelli American Jazzmaster-style pickguards, including options such as:
- Aged Pearl
- Black Pearl
- Cream
- 3-Ply White
- Black
- White Pearloid
- Vintage Tortoise
- Brown Tortoise
- Mint Green
- Parchment / Aged White
Pickguard availability may vary. These are designed around the 13-hole, 60’s Vintage American Jazzmaster-style layout.
Important Fitment Notes
This assembly is intended for American Jazzmaster-style 13-hole pickguards. Some imported Jazzmaster-style guitars, Squier models, reissues, or modified bodies may use different hole patterns, cavity routing, switch locations, or control spacing.
Please compare your guitar carefully before ordering. Minor fitting, drilling, or adjustment may be required depending on the body and model.
Pickups are not included. You will need to install your own Jazzmaster pickups and connect them to the harness.
Perfect For
- Jazzmaster upgrades
- Offset guitar builds
- Players replacing weak factory electronics
- DIY builders who want a cleaner starting point
- Customers who want the harness professionally mounted before installation
- Anyone who wants premium wiring without doing the full Jazzmaster layout from scratch
Built by Carparelli Guitars
Each loaded pickguard wiring kit is assembled with care by Carparelli Guitars using quality components, clean soldering practices, and a player-focused approach. This is a practical upgrade for anyone looking to bring more reliability, clarity, and control to their Jazzmaster-style guitar.
What You Receive
You will receive one selected Jazzmaster-style pickguard with the Carparelli Jazzmaster wiring kit professionally installed.
Pickups are not included.
Final pickup installation and guitar fitment are the responsibility of the buyer.
