L.R. Baggs Venue DI Acoustic Guitar Direct Box and Preamp
This seller has not set a shipping cost for Belgium. Please contact them to ask about shipping.
Only 1 left
Grab it before it's gone
Our users rate Reverb
Get the perfect acoustic tone.
The LR Baggs Venue DI Acoustic Direct Box offers a discrete acoustic guitar preamp. It combines a transformer-coupled DI output for maximum isolation, an EQ specifically tuned for acoustic guitars, a variable-boost control to complement your playing styles, and a chromatic digital tuner to help you stay in tune. Combining features from at least three stompboxes into one pro box, the LR Baggs Venue D.I. brings a new level of fidelity, confidence, and usefulness to performing acoustic musicians. The Venue D.I. is one of the most comprehensive and best-sounding tools ever to tame the surliest stage.
Features
- High-end audio transformer coupled XLR for full immunity from ground loops
- 100% Discrete circuitry and EQ for sweet transparent and ultra quiet sound
- Adjustable gain to handle most passive and active inputs
- Garret Null notch filter to non-destructively handle feedback
- Full chromatic tuner with footswitch mute/tune function
- Bomber construction with metal shaft potentiometers
- Phase inversion for best sound and feedback control
- Works with 9V battery or DC adapter (not included)
- Tunable low and high mid controls
- Adjustable solo boost foot switch control
- Real VU meter to accurately set gain
- 4-segment battery status gauge
- 1/4" input
- Input Impedance 10 mOhms
- Preamp Gain -12dB to +26dB
- Input Level -25dBv to +1.8dBv (.053Vrms to 1.23Vrms)
- EQ
- Notch -21dB, sweepable from 60Hz to 320Hz, 1/8 Octave
- Bass +/- 12dB @ 90Hz
- Lo Mid +/- 12dB @ 250Hz, sweepable from 100Hz to 500Hz
- Hi Mid +/- 12dB @ 1kHz, sweepable from 500Hz to 2.8kHz
- Presence +/- 12dB @ 3kHz
- Treble +/- 12dB @ 10kHz
- Effects Loops
- Send Level 0 dBv (0.707Vrms)
- Output Impedance 600 Ohms
- Return Level 0dBv (0.707Vrms) Maximum before clipping
- Input Impedance 80 kOhms
- D.I. OUT
- Output level -1dBv (0.88Vrms) Balanced
- Output impedance 600 Ohms (Transformer coupled)
- LINE OUT
- Output level -1dBv (0.88Vrms) Un-balanced
- Output impedance 200 Ohms
