Custom Handwired 200W "Bass" Head w/ 2ch, Master Volume and KT88 Power tubes

200W of pure valve-driven Hiwatt Headroom. The DR201 occupies the sweetspot between crystal clean and silky overdrive.

Push the channel volume or jump the channels for dirt and saturation. Though synonymous with famous bass recordings past and present, has proven itself in the production of unparalleled guitar tones. The iconic British sound trusted by musicians and engineers for generations.

FEATURE OVERVIEW

— Faithfully hand-wired according to Dave Reeve's original late 60's circuit design.

— A unique, silky character set apart by the KT88 output valve quartet.

— Hiwatt is the premier Pedal platform prized for clarity and Headroom. Presents Pedals true to your sound

— no effects loop requiRed.

— Normal and Bright channels with independent High and Low impedance inputs for each channel. Versatile and intuitive, perfect for bringing life out of dark pickups or taming shrill high end in bright pickups.

— Link the two channels for extra punch and dynamic control of your EQ via the independent channel volumes. Unleash the ’jumped’ channel sound Hiwatt is famous for.

— All the clean Headroom you could want.

— AP / Truly All Purpose Amplifier. Historically used by the world's most influential artists on a wide range of instruments in the studio and on stage. Ideal for amplifying bass, keys, synthesizers, guitars and other full-range and acoustic instruments.

Specs

wattage 200W

channels Normal, Brilliant

inputs

• Normal Hi
• Normal Low
• Brilliant Hi
• Brilliant Low

output 2 x 1/4" Speaker Out

preamp valves 3 x ECC83 (12AX7), 1 x ECC81 (12AT7)

output valves 4 x KT88

controls

• Normal Volume
• Brilliant Volume
• 3-Band EQ shared by both channels — Bass, Treble, Middle
• Presence — Treble Boost shared by both channels
• Master Volume
• Standby — On/Off
• Mains — On/Off

impedance Switchable using Impedance Selector on the rear panel — 4 Ω, 8 Ω, or 16 Ω

height 285mm (~12")

width 700mm (~28")

depth 295mm (~12")

weight 29.15 Kg (~65 lbs)

Road Ready — Rugged 18mm Birch-Ply Construction

Band Ready — ’Soak Tested’ by our Custom Shop Technicians

Touring Ready — World Voltage and Impedance Selectors

Based on Hiwatt’s original circuit designed by Dave Reeves.

Original Partridge spec English transformers. Meticulously hand-wired to Harry Joyce’s exacting military standards.

🇬🇧 Proudly manufactured in the Hiwatt Custom Shops.
