• SPECS
    • neck type AZRoasted Maple neck
    • top/back/body Flamed Maple topAlder body
    • fretboard Jatoba fretboardWhite dot inlay
    • fret Jumbo Stainless Steel frets
    • number of frets 24
    • bridge T106 bridge
    • string space 10.5mm
    • neck pickup Ibanez Modern Custom (H) neck pickupPassive/Alnico
    • bridge pickup Ibanez Modern Custom (H) bridge pickupPassive/Alnico
    • factory tuning 1E,2B,3G,4D,5A,6E
    • string gauge .010/.013/.017/.026/.036/.046
    • hardware color Chrome
  • NECK DIMENSIONS
      • Scale : 648mm/25.5"
      • a : Width 42mm at NUT
      • b : Width 57mm at 24F
      • c : Thickness 20.5mm at 1F
      • d : Thickness 22.5mm at 12F
      • Radius : 305mmR
    • DESCRIPTION

  • SWITCHING SYSTEM

    DESCRIPTION

  • CONTROLS

    DESCRIPTION

  • OTHER FEATURES
    • Recommended Case M300C
    • Locking machine heads
    • dyna-MIX10 switching system w/Alter Switch
Features Roasted Maple neck

The Roasted Maple neck is heat-treated to increase stability, durability, moisture resistance and tolerance of temperature changes.

Jatoba fretboard

Jatoba has a reddish brown color and produces a rich mid range with a crisp high end.

Jumbo Stainless Steel frets

Stainless steel frets boast excellent corrosion resistance. The wide and tall fret-type offers a quick response and effortless articulation when playing chords and clear tone when playing single notes.

Locking machine heads

Locking machine heads ensure accurate and stable tuning.

Flamed Maple top / Alder body

The Flamed Maple top displays a beautiful wood grain. The Alder body delivers a well-balanced bright tone, enriched resonance and sustain.

Ibanez Modern Custom pickups

Ibanez Modern Custom pickups feature a dual humbucker configuration with alnico V magnets. They offer powerful tone and a quick response, which pair especially well with overdrive and distortion.

T106 tremolo

The T106 tremolo bridge with 6 independent saddles makes precise height and intonation adjustment of each string easy.

dyna-MIX10 switching system with Alter Switch

The dyna-MIX 10 offers ten sound variations and can easily switch from humbucker and single coil modes with the mini switch. The power Tap mode provides a realistic single coil sound despite its two humbucker pickup layout.

Super All Access Neck Joint

The Super All Access Neck Joint increases playability and allows for easy access to the higher frets.

ConditionBrand New (New)
Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more
Brand
Model
  • AZ24S1F-TXB Standard
Finish
  • Transparent Turquoise Burst
Categories
Year
  • New
Color Family
  • Blue
Series
Right / Left Handed
  • Right Handed
Body Shape
  • S-Style
Fretboard Material
  • Jatoba
Number of Strings
  • 6-String
Neck Material
  • Maple
Offset Body
  • Non-Offset Body
Finish Pattern
  • Sunburst
Finish Style
  • Gloss
Body Type
  • Solid Body
Body Material
  • Alder
Bridge/Tailpiece Type
  • Tremolo Bridge
Pickup Configuration
  • HH
Top Material
  • Maple
Model Family
  • Ibanez AZ
Scale Length
  • 25.5"
Neck Construction
  • Bolt-On
Wood Top Style
  • Flamed
Number of Frets
  • 24
