Kluson 6 In Line Deluxe Series Tuning Machines - Double Line - Nickel With Oval Plastic Buttons

Kluson 6 In Line Deluxe Series Tuning Machines

ThisKluson 6-in-line tuning machine set has oval metal (butterbean-shaped) buttons and the improved 15:1 gear ratio for more stableand accurate tuning. The housing and button style are period correctfor various production dates although the black plating color was neveravailable until the mid 1990's. These feature the Kluson SafeTi StringPost. This set comes complete with 6 bass side tuning machines, 8.8mmO.D. vintage bushings with 1/4 inch I.D. and mounting screws needed forinstallation.

Specifications:

• Gear Ratio= 15:1
• Post to Post spacing= 15/16 in.
• Bushing size 8.8mm O.D. x 1/4 in. I.D.
• Typically used on right-handed instruments
• Pleasenote that Kluson Deluxe Series tuning machines come standard withvintage-sized bushings and mounting screws. If you have 10mm pegholes(modern sized) you will need to purchase the proper adapter bushingswith 1/4 in. I.D. dimensions.

Historical Info:

• 1965 - 1967 Fender Telecaster
• 1965 - 1967 Fender Stratocaster
• 1965 - 1967 Fender Jazzmaster
• 1965 - 1967 Fender Jaguar
• 1965 - 1967 Fender Custom Telecaster
• 1965 - 1967 Fender Coronado II
• 1965 - 1966 Fender Electric XII 12 string (need 1 left and 1 right hand set)
• 1965 Fender Fender Bass IV (6 string bass)
• 1965 - 1967 Fender Kingman
• 1965 - 1967 Fender Concert
• 1965 - 1967 Fender Malibu 12 string
• 1965 - 1967 Fender Shenandoah 12 string

Uses Kluson Bushings MB65N US (Nickel) or MB65G US (Gold)

• Outside diameter = 8.85mm
• Inside diameter = 1/4 inch or 6.48mm
