A.I.R.port

Through intensive research and development, we have designed the A.I.R.port with a unique internal structure that reflects sound waves and guides them to exit from a precisely positioned sound hole. As a result, players can monitor what they are playing more clearly, which enhances the overall playing experience.

Thermo Aged Ovangkol fretboard

Thermo Aged, a special drying process, makes the Ovangkol fretboard light and harder and provides increased stability.

Solid Sitka Spruce top

Solid Sitka Spruce top provides an enormous frequency range that offers wave after wave of shimmering highs along with tight mids and a full-bodied low end.

Ovangkol back and sides

Ovangkol back and sides offers well-balanced tones with a full-bodied mid range and a sparkling treble.

Thermo Aged Ovangkol Scalloped bridge

The lightweight, scalloped bridge enhances vibration transfer for improved resonance and offers greater flexibility when adjusting the action compared to a traditional bridge. Thermo Aged, a specialized drying process, makes the bridge even lighter and harder for increased stability.

Ibanez AEQ-TP2 preamp w/Onboard tuner

The Ibanez AEQ-TP2 preamp provides the extra punch of on-board EQ along with a convenient and easy-to-read digital tuner and 2-band EQ, located on the instrument’s upper bout.

AE body shape

Designed for projection, balance, and comfort, the AE's perfectly crafted contemporary body shape offers the best of all worlds.

Comfort Grip Nyatoh neck

The Comfort Grip Nyatoh Neck contour provides superior playability.

Ibanez T-bar Undersaddle pickup

The Ibanez T-bar Undersaddle pickup accurately translates that full sound to whatever amplification system you plug it into.

Ibanez Advantage bridge pins

These pins really are an advantage over old-fashioned pins. Advantage pins are easier to take out and easier to put in than standard pins. A special bulb-shaped end makes the pin easy to grip and also prevents the pin from being pushed in too far. Best of all, with Advantage the pin and string stay put.

Preamp

The neck side of the preamp is the top of the control panel. There is one button switch and three knobs towards the top of the control panel. The button furthest left is the tuner on/off switch. To the right of that are the bass, treble, and volume knobs.

Features

• Body Shape : AE (Shallower body depth) body
• Bracing : X-M Bracing
• Top : Solid Sitka Spruce Top
• Back & Sides : Ovangkol back & Ovangkol sides
• Neck : Comfort GripNyatoh neck
• Fretboard : Thermo Aged Ovangkol fretboard
• Bridge : Thermo Aged Ovangkol Scalloped bridge
• Inlay : Specially designed Abalone inlay
• Soundhole Rosette : Abalone
• Tuning Machine : Chrome Die-cast tuners (18:1 gear ratio)
• Number Of Frets : 20
• Bridge Pins : Ibanez Advantage
• Strings : D'Addario XTAPB1253
• String Gauge : .012/.016/.024/.032/.042/.053
• String Space : 11mm
• Factory Tuning : 1E,2B,3G,4D,5A,6E
• Pickup : Ibanez T-bar Undersaddle
• Preamp : Ibanez AEQ-TP2 preamp w/Onboard tuner
• Output Jack : Balanced XLR & 1/4" outputs
• Battery : 9V x1
• Case not included

Body Dimensions

• a : Length : 20 1/8"
• b : Width : 16 1/4"
• c : Max Depth : 4 1/2"

Neck Dimensions

• Scale : 634mm/25"
• a : Width : 43mm at NUT
• b : Width : 54.33mm at 14F
• c : Thickness : 20mm at 1F
• d : Thickness : 21mm at 7F
• Radius : 400mmR
