Ultra-low latency operation with USB or FireWire, combined with the legendary RME driver stability and maintenance. Active jitter suppression, individually switchable reference levels for all inputs and outputs, full stand-alone functionality, RME’s unique DIGICheck metering and analysis toolbox, and identical operation on Windows PC and Mac.

Key Features

\n
• 30 Input / 30 Output channels
\n
• Four definable groups for Solo, Mute and Faders
\n
• Switchable Mono and Stereo channel view
\n
• Channel Options: Stereo Width, MS Processing, Phase L/R
\n
• Unlimited Undo and Redo
\n
• Slim channel mode for selected or all channels, to save space or give a meter bridge view
\n
• 2 Row Mode: reduces the height of the mixer to two rows for smaller displays
\n

Technical Specifications

AD, Line In 1-8, rear\nResolution AD\n24 bit\nSignal to Noise ratio (SNR)\n113 dB RMS unweighted, 116 dBA\nFrequency response @ 44.1 kHz, -0.1 dB\n5 Hz - 20.8 kHz\nFrequency response @ 96 kHz, -0.5 dB\n5 Hz - 45.8 kHz\nFrequency response @ 192 kHz, -1 dB\n5 Hz - 92 kHz\nTHD\n< -110 dB, < 0.00032 %\nTHD+N\n< -104 dB, < 0.00063 %\nChannel separation\n> 110 dB\nInput\n6.3 mm TRS jack, electronically balanced\nInput sensitivity\n8 kOhm unbalanced, 12 kOhm balanced\nInput sensitivity\nswitchable to Lo Gain, +4 dBu, -10 dBV\nInput level for 0 dBFS @ Lo Gain\n+19 dBu\nInput level for 0 dBFS @ +4 dBu\n+13 dBu\nMicrophone In 9-12, front\nAs AD, but:\nInput\nXLR, electronically balanced\nInput impedance\n3.4 kOhm\nSignal to Noise ratio (SNR)\n112 dB RMS unweighted, 116 dBA\nGain range\n54 dB\nMaximum input level, Gain +6 dB\n+10 dBu\nInstrument In 9-12, front\nAs AD, but\nInput\n6.3 mm TS jack, unbalanced\nInput impedance\n800 kOhm\nSignal to Noise ratio (SNR)\n112 dB RMS unweighted, 115 dBA\nMaximum input level, Gain +6 dB\n+21 dBu\nDA, Line Out 1-8, rear\nDynamic range (DR)\n115 dB RMS unweighted, 118 dBA\nFrequency response @ 44.1 kHz, -0.5 dB\n5 Hz - 20.8 kHz\nFrequency response @ 96 kHz, -0.5 dB\n5 Hz - 45 kHz\nFrequency response @ 192 kHz, -1 dB\n5 Hz - 89 kHz\nTHD\n-110 dB, < 0.00032 %\nTHD+N\n-104 dB, < 0.00063 %\nChannel separation\n> 110 dB\nOutput\n6.3 mm TRS jack, servo-balanced\nOutput impedance\n75 Ohm\nOutput level switchable Hi Gain, +4 dBu, -10 dBV\nOutput level at 0 dBFS @ Hi Gain\n+19 dBu\nOutput level at 0 dBFS @ +4 dBu\n+13 dBu\nOutput level at 0 dBFS @ -10 dBV\n+2 dBV=\nDA - Stereo Monitor Output Phones (9-12)\nAs DA, but\nOutput\n6.3 mm TRS stereo jack, unbalanced\nMaximum output level at 0 dBFS, High\n+16.8 dBu\nMaximum output level at 0 dBFS, Low\n+2 dBV\nOutput impedance\n30 Ohm\nAES/EBU\n2 x XLR, transformer-balanced, galvanically isolated, according to AES3-1992\nADAT Optical\n2 x TOSLINK I/O, format according to Alesis specification\nStandard\n2 x 8 channels 24 bit, up to 48 kHz\nDouble Speed (S/MUX)\n2 x 4 channels 24 bit 96 kHz\nQuad Speed (S/MUX4)\n2 x 2 channels 24 bit 192 kHz\nQuad Speed Windows USB\n1 x 2 channels 24 bit 192 kHz\nSPDIF optical (via ADAT2)\n1 x optical, according to IEC 60958\nWord Clock\nBNC, switchable termination
