Playing live is about living in the moment. Make those moments count with the V-STAGE76.

Offering artistic command and natural playability, it combines Roland’s cutting-edge sound technologies with an intuitive workflow so you can play what's in your soul. The newly developed 76-note semi-weighted keyboard provides a refined velocity response and an organ-style waterfall feel, making it ideal for expressive playing techniques like glissandos and rakes. With four independent sound engines, including acoustic and electric piano engines, a powerful organ model, and a versatile ZEN-Core synthesizer, you can access an expansive range of tones tailored for every genre and performance style.

Built for the stage, the V-STAGE features a hands-on interface with dedicated controls for each sound engine, allowing instant adjustments and fluid transitions between sounds. The powerful Scene system lets you store and recall complete keyboard setups, while the EX Scenes feature makes on-the-fly sound creation a breeze. A comprehensive effects section includes independent delay, reverb, multi-effects, and a master compressor and EQ to refine the output for any venue. With extensive connectivity options, including balanced XLR and ¼-inch outputs, USB-C audio/MIDI integration, and multiple pedal inputs, the V-STAGE helps you adapt to any situation quickly and easily so you can focus on the performance.

Roland V-STAGE 76 Includes

• Owner's Manual
• Power cord

Roland V-STAGE 76 Features

• Premium keyboards designed for professional stage performers
• 76 semi-weighted keys and organ-style waterfall feel
• Four independent sound engines powered by Roland’s most advanced modeling and sound technologies
• Acoustic Piano engine developed with V-Piano technology; includes two concert grands, an upright piano, a felt piano, and Piano Designer tools for deep sound customization
• Newly developed Electric Piano engine with the latest SuperNATURAL advancements; includes Tine, Reed, Digital, and Clavinet types with customizable sound parameters, adjustable key touch, and dedicated EP effects
• Organ engine with a three-part console model driven by Virtual Tone Wheel technology, two vintage transistor types, a pipe organ type, and new overdrive and rotary speaker effects
• ZEN-Core Synthesizer engine with over 400 onboard sounds and support for SDZ Sound Packs and Model Expansions on Roland Cloud (JUPITER-8, JUNO-106, JX-8P, and SH-101 Model Expansion titles are free downloads for registered V-STAGE owners)
• Intuitive panel layout with discrete sections and hands-on controls for the sound engines and effects
• Store and recall complete keyboard setups with 512 Scenes
• Easily manage complex setlists with 128 Scene Chains
• Eight special EX Scenes with auto-save for building setups in the moment
• Total Effects section with independent delay and reverb plus legendary Roland multi-effects
• Master section with compressor and EQ for shaping the sound output for different venues
• Comprehensive audio connectivity with balanced XLR and 1/4-inch main stereo outputs and two balanced sub outputs
• XLR microphone input with panel volume control
• Stereo line inputs for external sources
• Class-compliant USB-C audio/MIDI interface for working with music software on computers and mobile devices
• USB memory port for data import and backup
• Two USB device ports for connecting MIDI controllers such as the Roland A-49 or A-PRO series
• MIDI I/O and four jacks for hold/damper pedals, footswitches, and expression pedals

Roland V-STAGE 76 Specifications

• Scenes: 512 (including pre-loaded registrations)
• Scene Chains: 128
• Effects
  • Multi-Effects: 16 systems, 93 types
  • Chorus: 9 types
  • Reverb: 7 types
  • External memory:USB flash drive (supports USB 2.0 Hi-Speed flash memory: Sold separately)
• Controllers
  • Assignable Wheel x 2
  • Assignable Switch x 2
  • DisplayGraphic: LCD 4.3 inch
• Connectors
  • PHONES jack: Stereo 1/4-inch phone type
  • MAIN OUT (L, R) connectors: XLR type
  • MAIN OUT (L/MONO, R) jacks: 1/4-inch TRS phone type
  • SUB OUT (L, R) jacks: 1/4-inch TRS phone type
  • LINE INPUT (L/MONO, R) jacks: 1/4-inch phone type jacks
  • MIC INPUT connector: XLR type
  • PEDAL (HOLD,CTRL1,CTRL2,CTRL3) jacks: 1/4-inch TRS phone type
  • MIDI (IN, OUT1, OUT2/THRU) connectors
  • USB COMPUTER port: USB Type-C(R) (Audio/MIDI Class Compliant)
  • USB MEMORY port: USB A
  • 2 x External Device Port(USB A):Roland A-49 or an A-PRO series MIDI Controller can be connected. * Operation is not guaranteed if a generic MIDI device is connected.
  • AC IN jack
• Power consumption: 30 W, Power consumption when in OFF mode (when the power automatically turns off): 0.3 W
• Accessories: Owner's Manual, Power cord
• Options (sold separately)
  • Keyboard stand: KS-13, KS-11Z
  • Piano pedal: RPU-3
  • Damper pedal: DP-10
  • Pedal switch: DP-2
  • Expression pedal: EV-5
  • USB flash drive (*)
  • * Use a commercially available USB flash drive. However, we cannot guarantee that all commercially available USB flash drives will work.
• Size and Weight
• Width
  • 1,181 mm
  • 46-1/2 inches
• Depth
  • *342 mm
  • 13-1/2 inches
• Height
  • 109 mm
  • 4-5/16 inches
• Weight (excluding AC adaptor)
  • 15.2 kg
  • 33 lbs 9 oz
