FBT CS-1000-BLK Portable Active Sub/Satellite Speaker System, 1000 Watts, Built-In DSP

The VERTUS CS1000 is a compact, powerful line array system that presents a sleek, modular design placing high-quality audio in environments from clubs to elegant aesthetic decors with ease. The bi-amplified system features a long-excursion 12-inch bass reflex subwoofer and a passive satellite unit with six 3-inch neodymium drivers, creating a well-balanced and articulate sound profile. The Class-D amplifier built into the subwoofer pushes 600W RMS to the low end and 400W RMS to the satellite, ensuring punchy bass, clear highs, and an impressive 129 dB Sound Pressure Level (SPL). Whether setting up for a gig or integrating into an existing installation, the CS1000’s blend of power, precision, and flexibility makes it an excellent choice for performers, DJs, corporate events, or any place where prominent audio and understated visuals go hand in hand.

Making it easy to get in / get out and get to the next show, the entire system packs neatly into the subwoofer enclosure for easy transport, including the satellite, mounting pole, and all necessary cables. The innovative locking system secures everything in place, making setup and teardown quick and hassle-free. The J-array configuration offers a 110° horizontal and 30° vertical dispersion, ensuring consistent coverage across a wide area. The fanless amplifier is housed in die-cast aluminum for long-term reliability, while onboard DSP provides eight custom presets tailored for different environments. With ergonomic aluminum handles and a rugged birch plywood construction, the VERTUS CS1000 is ready to handle whatever comes its way.

FBT Vertus CS1000 Features

• 2-way speaker system
• Subwoofer with a custom 12" (320mm) long excursion speaker with a 2.5" (64mm) voice coil
• 6 x full-range, 3" (70mm) neodymium high efficiency custom woofers with 0.75" (20mm) voice coils
• Frequency response of 40Hz to 20KHz
• Onboard Class-D, switch-mode amplifier delivering 600Wrms + 400Wrms for LF and HF respectively
• Built-in DSP with eight presets to suit every application
• Variable volume between -4.5 / + 5 dB in 8 steps
• Control Panel with master volume, presets, satellite volume, HPF, and LED status
• Input and link via XLR and Neutrik SPEAKON for satellite connection
• Dispersion 110 ° (H) x 30 ° (V)
• Modular design allowing two systems to be configured as one single solution via optional accessories
• Bass reflex stackable subwoofer in a birch plywood enclosure with die-cast aluminium handle and rubber inserts, plus M20 support and a custom pole-mount solution
• facilitating adjustable height and vertical aiming
• The satellite and pole are fully integrated into the subwoofer cabinet, where a push button system locks the satellite in place for transportation
• The satellite is equipped with a coupling system for accessories which allow the extension of the length of the line array, positioning one atop the other. Alternatively, the same system allows the satellite to be permanently wall-mounted.
• Ideal for both live applications and fixed installations
• Easily expandable to a total power of 8.000W peak (via a stereo system consisting of 4 x VERTUS CS1000, positioned two per side)

FBT Vertus CS1000 Specifications

• Configuration: 2-way
• Built-in amplifier RMS: 600 / 400 Watts
• Built-in amplifier Peak: 1200 / 800 Watts
• frequency response: 40Hz - 20kHz
• Woofer: 320mm / 12"
• High frequency driver: 6 x 70mm / 2,75"
• Max. SPL (cont/peak): 125 / 129 dB
• Dispersion: 110° x 30°
• Input impedance: 22 kOhms
• Crossover frequency: 1.8kHz
• AC power required: 640VA
• Input connections: XLR with loop
• Dimensions
  • Satellite
    • 4,09 x 20,86 x 4,56 (inches)
    • 104 x 530 x 116 (mm)
  • Sub
    • 22,24x 15,27 x 17,71 (inches)
    • 565 x 388 x 450 (mm)
• Net weight: 66.13 lb / 30 kg
