ETC E-SPS-DIN Echo DIN Rail-Mount Station Power Supply with Auxiliary Power

ETC's EchoConnect® DIN Rail Station Power Supply provides EchoConnect bus power for up to 16 sensors/stations and 16 power controllers as well as Aux 24VDC for Echo products that require it. This product consists of two components that must be used together: the EchoConnect Power Supply and the 24VDC Aux supply that feeds it DC power.

The EchoConnect DIN Rail Station Power Supply is designed to be used with the Unison Echo® DMX Scene Controller, a member of ETC's Unison Echo family of lighting-control and power-control products.

ETC E-SPS-DIN EchoConnect Rail Station Power Supply Includes:

• (1) EchoConnect DIN Rail Station Power Supply
• (1) 24VDC DIN rail mount power supply
• (1) Red and black power harness
• (1) Green station header

ETC E-SPS-DIN EchoConnect Rail Station Power Supply Specifications:

• Functions:
  • Provides EchoConnect power for up to 16 stations or sensors and 16 power controllers or panels
  • Supports 1640 ft (500 meters) of control wiring
  • Mains input 100-240VAC, 50/60 Hz, provides 30W at 24VDC in addition to the power required for the Station Power Supply
• Thermal:
  • Ambient room temperature: 32-122°F / 0-50°C
  • Ambient humidity: 5-95% non-condensing
• Compliance:
  • UL and cUL listed
  • FCC and CE compliant
• Dimensions: 3.88" H x 3.9" D x 2.96" W (9.9 x 9.9 x 7.5 cm)
• Weight: 1 lb (0.45 kg)
