The CHO-mini features three carefully crafted, yet distinct chorus flavors. All three modes faithfully capture those iconic modulation tones that have shaped music across genres, past and present and are simply selected by the pedal's convenient mode switch right on the face of the pedal.

"Chorus 1"
This emulates the coveted and well-established bucket-brigade style of chorus pedal tones from the 70s. You know, "THAT" CHORUS sound that is instantly recognisable from many popular recordings.

"Chorus 2"
Based on a different flavour of stereo chorus, "Chorus 2" allows for a higher rate towards the end of the control range, enabling pleasing vibrato like textures.

"Flanging"
While not a flanger tone in a traditional sense, this mode emulates another extremely popular (and rare and expensive in its original form) chorus pedal from the 70s, in its subtle flanging mode. Use of this as a comb-filter phasing of the signal (like feedback on delay), focusing on its luscious general character and without becoming too extreme.

Adding to its flexibility, the CHO-mini features full tap tempo functionality, but in a single switch design. Simply holding the footswitch for approximately two seconds enters the pedal into "Tap Tempo" Mode, following which the pedal will respond to rhythmic toe tapping instantly.

Further defying expectations based on its compact appearance, there are dedicated toggles for selection between mono and stereo (TRS) operation as well as true or buffered bypass modes, making the pedal suitable for almost any musical situation, anywhere, any time.
As with all other current Nobels pedals, the CHO-mini features 4 integrated Mounty-P Mounting Plates for safe and secure attachment to pedalboards. With its full metal enclosure and Glow in the Dark pointer knobs, the CHO-mini is a pint-sized powerhouse that's built for performance

SPECIFICATIONS
Power (DC): stabilized & filtered power supply 9 Volt DC (optional)
Power connector: 2.1 mm / negative center
Consumption: less than 100 mA
Input Impedance: 1M Ohm
Output Impedance: 10K Ohm Max.
Input Level: Typical 6.6 dBu (1 kHz - 1% THD+N)
Dynamic Range: Typical 106 dB (w/o effect through DSP Buffer)
DSP
Processor: 48 kHz/32 bit - A/D D/A
Sampling Rate 48 kHz/ 32 bit
Controls: Width, Depth, Rate (Glow In The Dark Pointer knobs)
Switches: Chorus 1 Mode, Chorus 2 Mode, Flanging Mode, Bypass, Mono-Stereo, On/Off (Tap Tempo)
Jacks: DC, Input TRS 1/4" (6.3 mm), Output TRS 1/4" (6.3 mm)
Indicator (LED): 1x Multicolor LED
- LED = green: On/Off
- LED = red: Mode
- LED = blue: Tap Tempo
Mounty-P: 4 integrated, fold-out Mounty-P Mounting Plates

• Dimensions (cm): LxWxH 9.37 x 4.85 x 5.13; 12 x 6.95 x 6.5 (boxed)
• Weight (gr): 210 / 301 (boxed)
• (Specifications are subject to change without notice)
