● Compact and complete, with both sound and function

●The same digital platform as GP-200 is equipped with the same high-definition digital modeling technology to create high-quality sound

● 24-bit/44.1kHz high sampling rate

● More than 240 high-quality effects based on high-definition digital modeling technology

- 140+ legendary guitar/bass/acoustic guitar preamps and IR cabinets

- 100+ dynamics/distortion/frequency/modulation/delay/reverb effects

● Supports storage of 20 user IRs

● 255 preset positions (99 factory presets, 156 user presets)

● 11 modules in the effect chain can be used simultaneously, and the order can be freely set

● Phrase loop function that can record up to 180 seconds

● 100 high-quality drum machine patterns

● Accurate and sensitive visual tuner

● 4.3-inch high-definition IPS LCD display presents an intuitive and friendly multi-language human-computer interaction interface

● 3 custom function lighted feet with 3 foot templates, flexible switching for different usage scenarios

● 6-input 4-output sound card supports RE-AMP and Loopback functions

● Smooth-feeling expression pedal that can control up to 3 effect parameters

● Multiple interfaces to meet the usage in different environments

- 6.35mm mono instrument input jack

- A set of stereo 6.35mm unbalanced output interfaces

- A set of stereo XLR balanced output interfaces

- A set of FX LOOP effect loop interface

- 3.5mm stereo headphone output jack

- 3.5mm stereo line input interface

- 6.35mm TRS external controller/foot spike connector

● USB Type-C interface provides sound card function and supports Win/Mac/iOS/Android operating systems

● Easy-to-use Win/Mac editing software

● Strong and durable metal casing

● 9V DC power supply

SPECIFICATIONS

A/D/A conversion: 24-bit high performance

Sampling rate: 44.1kHz

Signal-to-noise ratio: 110dB

Effect modules: 11, can be used simultaneously

Number of presets: 255 preset positions, 99 factory presets

Phrase looper maximum recording time: 180 seconds

Built-in drum machine: 100 rhythm patterns

Analog Input Connections

Guitar input: 6.35mm unbalanced input (TS)

Input Impedance: 4.7MOhms (Acoustic Guitar), 1M Ohms (Electric Guitar), 10k Ohms (Line Input)

Return input: 6.35mm unbalanced input (TS)

Return input impedance: 100k Ohms

Aux input: 3.5mm stereo input (TRS)

Aux input impedance: 10k Ohms

Analog output connections

Left and right unbalanced output: 6.35mm TRS interface

Left and right unbalanced output impedance: 1k Ohms

Left and right balanced output: XLR interface

Left and right balanced output impedance: 1k Ohms

Send output: 6.35mm unbalanced output (TS)

Send output impedance: 1k Ohms

Headphone output: 3.5mm stereo output (TRS)

Headphone output impedance: 22 Ohms

Digital Connection

USB port: USB2.0 Type-C port

USB Recording Specifications

Sampling frequency: 44.1kHz

Sampling depth: 16-bit or 24-bit

Size and weight

Dimensions: 281mm (length) × 166mm (width) × 57mm (height)

Weight: 1.55kg

Power supply requirements: DC 9V, 1000mA, negative inside and positive outside.

Shipping Dimensions: 12 x 5 x 3 inches

Shipping Weight: 4 lbs
