The Sea Machine is a chorus pedal with as many modulation possibilities as there are fish in the ocean. That’s a lot of fish. And a lot of modulation. From subtle, shimmery chorus sounds, to wobbly, seasick, warbly pitch-bent detuning that rocks the boat, the Sea Machine is the audio bait that’ll help you reel in the big one.

The Sea Machine ain’t no one-trick seahorse. With a mix of standard and unique controls, everything from subtle warble, classic Leslie, seasick pitch bends, strangled alien sounds, stunted arpeggiations, and many more far-out sounds are available. Or you could just use it as a chorus. That works, too. Oh, and if you’re a bass player who fancies themselves a fan of the classic 80s post-punk bass sound, the Sea Machine is pretty much just like (tone) heaven.

Controls

1. Animate: How far the pitch-shifted signal swings, lower levels equal a tighter and more focused shift à la traditional chorus. As you increase the control a more wild and animated pitch shift begins to emerge.
2. Dimension: Adds a slight slap-back at low levels, the reverb-like ambiance at mid-levels, and an echo-resonance that will lead to self-oscillation at max.
3. Intensity: Adjusts how much-modulated signal is blended in with the dry signal. Unity for this control is right around noon, everything above that is boosting the modulated signal.
4. Depth: Adjusts how strongly the LFO modulates the delay time.
5. Shape: Goes from triangle wave to square wave as you turn clockwise.
6. Rate: This sets the speed of the LFO. The miniature LED will blink to the tempo, even in bypass mode.

Suggested Settings

• Haunting Slow Modulations
• Sequential Roots & Fourths

Features

Dimensions

• 4.75 x 2.50 x 2.25 in. (121 x 64 x 57 mm) with knobs

Current Draw

• 40 mA

Input Impedance

• 10 kO

Output Impedance

• <1 kO

Flexi-Switch Technology

• This device features Flexi-Switch Technology! This relay-based, true bypass switching style allows you to simultaneously use momentary and latching style switching.
• For standard latching operation, tap the footswitch once to activate the effect and then tap again to bypass.
• For momentary operation, hold the footswitch down for as long as you’d like to use the effect. Once you release the switch the effect will be bypassed.
• Since the switching is relay-based, it requires power to pass the signal.

Power

• This device takes a standard 9-volt DC power supply with a 2.1mm negative center barrel. We always recommend pedal-specific, transformer-isolated wall-wart power supplies or multiple isolated-output supplies. Pedals will make extra noise if there is ripple or unclean power. Switching-type power supplies, daisy chains, and non-pedal specific power supplies do not filter dirty power as well and let through unwanted noise. DO NOT RUN AT HIGHER VOLTAGES!
