When the pickup selector switch is in the neck position, the neck pickup is selected. When the switch is between the neck and center position, the neck humbucker is selected and is in parallel. When the switch is in the center position, both neck and bridge pickups are selected. When the switch is in between the center and bridge position, the bridge side of the neck pickup and the neck side of the bridge pickup are selected. When the switch is in the bridge position, the bridge pickup is selected.
With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.
F106 bridge
The F106 bridge enriches sustain. String height adjustment can be done easily and independently.
Jatoba Fretboard
Jatoba has a reddish-brown color which produces a rich mid-range with a crisp high end.
Wizard III Maple Neck
Ibanez's thin, flat, and fast Wizard neck is strong and sturdy offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.
Quantum Pickups
The Quantum pickups provide an accelerated bass response for exceptionally fast tracking of high-speed staccato riffing with crushing mid-range and precise high-end articulation.
Features
- Neck Type : Wizard III / Maple neck
- Top/Back/Body : Quilted Maple top / Meranti body
- Fretboard : Jatoba fretboard / White dot inlay
- Fret : Jumbo frets
- Number of Frets : 24
- Bridge : F106 bridge
- String Space : 10.5mm
- Neck Pickup : Quantum (H) neck pickup (Passive/Ceramic)
- Bridge Pickup : Quantum (H) bridge pickup (Passive/Ceramic)
- Factory Tuning : 1E,2B,3G,4D,5A,6E
- Strings : D'Addario EXL110
- String Gauge : .010/.013/.017/.026/.036/.046
- Hardware Color : Black
- Scale : 648mm/25.5"
Neck Dimensions
- A : Width : 43mm at NUT
- B : Width : 58mm at 24F
- C : Thickness : 19mm at 1F
- D : Thickness : 21mm at 12F
- Radius : 400mmR
| Condition | Mint (Used) Mint items are in essentially new original condition but have been opened or played.Learn more |
|---|---|
| Brand | |
| Model |
|
| Finish |
|
| Categories | |
| Color Family |
|
| Series | |
| Body Shape |
|
| Right / Left Handed |
|
| Fretboard Material |
|
| Number of Strings |
|
| Wood Top Style |
|
| Neck Material |
|
| Offset Body |
|
| Finish Pattern |
|
| Finish Style |
|
| Body Type |
|
| Pickup Configuration |
|
| Nut Width |
|
| Top Material |
|
| Bridge/Tailpiece Type |
|
| Model Family | |
| Scale Length |
|
| Neck Construction |
|
| Number of Frets |
|
