Super Wizard 5pc Maple/Walnut Neck

The Super Wizard 5pc Maple/Walnut neck provides extra-smooth playing.

V7 / S1 / V8 Pickups

The RG can dial in any tone, from crystal clear to searing and nasty, thanks to its V7 neck pickup, S1 middle pickup and V8 bridge pickup combination.

Maple Fretboard

The maple fretboard provide crisp, bright highs and strong upper mids.

Edge Tremolo Bridge

The masterpiece Edge bridge offers exceptional tuning stability, precise intonation adjustment, and playing comfort.

Gotoh Machine Heads

Gotoh machine heads provide super precision, smooth feel, and minimal back lush.

With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch. When the pickup selector switch is in neck position, the neck humbucker is selected. When the switch is between neck and center position, the bridge side of the neck humbucker and the center pickup are selected. When the switch is in center position, the center pickup is selected. When the switch is between the center and bridge position, center pickup and the neck side of the bridge humbucker are selected. When the switch is in bridge position, the bridge humbucker is selected.

Features

  • Neck type : Super Wizard5pc Maple/Walnut neck
  • Top/back/body : Basswood body
  • Fretboard : Maple fretboard Black dot inlay
  • Fret : Jumbo frets
  • Number of frets : 24
  • Bridge : Edge bridge
  • String space : 10.8mm
  • Neck pickup : V7 (H) neck pickup Passive/Ceramic
  • Middle pickup : S1 (S) middle pickup Passive/Alnico
  • Bridge pickup : V8 (H) bridge pickup Passive/Alnico
  • Factory tuning : 1E,2B,3G,4D,5A,6E
  • Strings : D'Addario EXL120
  • String gauge : .009/.011/.016/.024/.032/.042
  • Nut : Locking nut
  • Hardware color : Black

Neck Dimensions

  • Scale : 648mm/25.5"
  • a : Width : 43mm at NUT
  • b : Width : 58mm at 24F
  • c : Thickness : 17mm at 1F
  • d : Thickness : 19mm at 12F
  • Radius : 430mmR

Guitar Neck Diagram

  • a : Width of the neck at the nut
  • b : Width of the neck at the fret position specified by the neck dimension
  • c : Thickness of the neck at the first fret
  • d : Thickness of the neck at the fret position specified by the neck dimension
  • Radius : Radius of the fingerboard

ConditionMint (Used)
Mint items are in essentially new original condition but have been opened or played.Learn more
Brand
Model
  • RG550-EB Genesis Collection
Finish
  • 678
Categories
Color Family
  • Blue
Right / Left Handed
  • Right Handed
Fretboard Material
  • Maple
Body Material
  • Basswood
Body Shape
  • S-Style
Pickup Configuration
  • HSH
Number of Strings
  • 6-String
Neck Material
  • Maple
  • Walnut
Offset Body
  • Non-Offset Body
Finish Style
  • Gloss
Bridge/Tailpiece Type
  • Locking Tremolo Bridge
Body Type
  • Solid Body
Wood Top Style
  • Opaque
Model Family
Finish Features
  • Matching Headstock
Scale Length
  • 25.5"
Neck Construction
  • Bolt-On
Number of Frets
  • 24
