Authorized Ibanez Dealer! Full Manufacturer Warranty!

Includes an Ibanez gig bag!

SPECS

Neck type EHB4 5pc Roasted Maple/Walnut neck w/Graphite reinforcement rods

Top/back/body American Basswood body

Fretboard Roasted Birdseye Maple fretboard Off-set Abalone dot inlay

Fret Medium Stainless Steel frets

Number of frets 24

Bridge MR5HS bridge

String space 19mm

Neck pickup Bartolini® BH2 neck pickup Passive

Bridge pickup Bartolini® BH2 bridge pickup Passive

Equaliser Vari-mid 3-band EQ w/ EQ bypass switch (passive tone control on treble pot)

Factory tuning 1G,2D,3A,4E

Strings D'Addario® EXL165

String gauge .045/.065/.085/.105

Hardware color Black

NECK DIMENSIONS

Scale : 864mm/34"

a : Width 41mm at NUT

b : Width 64mm at 24F

c : Thickness 19.5mm at 1F

d : Thickness 21.5mm at 12F

Radius : 500mmR

FEATURES

Ergonomic body design

The EHB’s headless construction and specially designed body enable the player to maintain a similar playing position whether seated or standing.

Slanted body back

The top half of the back of the body is slanted which allows the bass to rest slightly closer to the player’s body for better control and a more ergonomic feel.

Comfortably rounded body edge, Chambered body

Its contoured, ergonomic design and chambered body make for a lightweight, well-balanced, and comfortable instrument that’s excellent for long sets or practice session.

Scooped cut on the body back

There is extra carving on the back of the body behind the lower horn for easier upper fret access.

5pc Roasted Maple/Walnut neck w/Graphite reinforcement rods

The Roasted Maple in the neck is heat-treated to increase stability, durability, moisture resistance, and tolerance of temperature changes.

Luminescent side dot inlays

Luminescent side dot inlay provides clear visibility in dark environments.

Bartolini® BH2 pickups

The Bartolini® BH2 pickups provide a tight bottom-end, punchy mid-range, and smooth response. The dual-coil style configuration maximizes articulation and a long blade pole piece widens the magnetic field, providing balanced string-to-string pickup response.

MR5HS mono rail bridge w/string spacing adjustable saddles

The MR5HS bridge is designed especially for the EHB basses and features wide intonation range. Each bridge piece is independently and securely attached to the body for maximum vibration transfer, and the saddles are adjustable for string spacing +/-1.5mm, answering every bassist’s individual string spacing demands, no matter what playing style. Teflon washers are used on each tuner for a smooth tuning action.
