When the pickup selector switch is in the neck position, the neck humbucker is selected. When the switch is between the neck and center position, the bridge side of the neck humbucker and the center pickup are selected. When the switch is in the center position, the center pickup is selected. When the switch is between the center and bridge position, center pickup and the neck side of the bridge humbucker are selected. When the switch is in the bridge position, the bridge humbucker is selected.

With the guitar held in the playing position, there is one knob and one switch along the lower edge of the body. Closest to the neck is the five-way pickup selector switch. Closer to the input jack is the tone knob. The volume knob is located right above the five-way pickup selector switch.

DiMarzio Air Norton / True Velvet / The Tone Zone Pickups

The DiMarzio Air Norton, True Velvet, and Tone Zone pickups offer depth, warmth, and rich dynamics when combined with the 5-way pickup switch.

Wizard III Roasted Maple Neck

Ibanez's thin, flat, and fast Wizard neck is strong and sturdy offers unlimited playability and features a two-octave 24-fret fretboard for a wide tonal range.

Nyatoh Body

Nyatoh used as the body wood provides a rich mid-low end.

Rosewood Fretboard

Rosewood provides a well-balanced solid tone with a focused mid-range.

Edge-Zero II Tremolo Bridge

The Edge Zero II bridge design features a lower profile tremolo for playing comfortably and a stud lock function for stable tuning.

Features

  • Neck Type : Wizard III / Roasted Maple neck
  • Top/Back/Body : Nyatoh body
  • Fretboard : Rosewood fretboard / Off-set white dot inlay
  • Fret : Jumbo frets
  • Number of Frets : 24
  • Bridge : Edge-Zero II bridge
  • String Space : 10.8mm
  • Neck Pickup : DiMarzio Air Norton (H) neck pickup (Passive/Alnico)
  • Middle Pickup : DiMarzio True Velvet (S) middle pickup (Passive/Alnico)
  • Bridge Pickup : DiMarzio The Tone Zone (H) bridge pickup (Passive/Alnico)
  • Factory Tuning : 1E,2B,3G,4D,5A,6E
  • Strings : D'Addario EXL120
  • String Gauge : .009/.011/.016/.024/.032/.042
  • Nut : Locking nut
  • Hardware Color : Black
  • Scale : 648mm/25.5"

Neck Dimensions

  • A : Width : 43mm at NUT
  • B : Width : 58mm at 24F
  • C : Thickness : 19mm at 1F
  • D : Thickness : 21mm at 12F
  • Radius : 400mmR

ConditionBrand New (New)
Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more
Brand
Model
  • S770-CZM Standard
Finish
  • 678
Categories
Finish Style
  • Satin
Fretboard Material
  • Rosewood
Body Material
  • Nyatoh
Color Family
  • Blue
Series
Body Shape
  • Double Cutaway
Right / Left Handed
  • Right Handed
Pickup Configuration
  • HSH
Number of Strings
  • 6-String
Neck Material
  • Maple
Offset Body
  • Non-Offset Body
Finish Pattern
  • Sunburst
Bridge/Tailpiece Type
  • Locking Tremolo Bridge
Body Type
  • Solid Body
Model Family
  • Ibanez S
Nut Width
  • 1.69"
Wood Top Style
  • Opaque
Finish Features
  • Matching Headstock
Scale Length
  • 25.5"
Neck Construction
  • Bolt-On
Number of Frets
  • 24
