High Performance Active Direct Injection Box

The Radial Pro48 is a compact high-performance 48V phantom powered active direct box designed specifically for todays high output instruments.

The Pro48's innovative internal switching power supply significantly increases headroom producing less distortion while yielding a smooth, linear response that extends from 20Hz to well above 40kHz. This results in natural, uncolored signal that is as good or better than DI boxes costing several times more. The superior performance makes the Pro48 an ideal candidate for use with battery powered active basses and acoustic guitars that tend to overload other direct boxes.

The compact Pro48 is built road-ready with 14 gauge steel throughout. A unique book-end design creates a protective zones around the switches and connectors while the internal I-beam construction assures outside stress will not torque the PC board and deteriorate solder connections. A full bottom no-slip pads adds mechanical isolation and electrical insulation to further extend the Pro48's lifespan.

Exceptional sonic performance, great natural tone and an affordable price tag! The Radial Pro48 truly represents a breakthrough in value.

Key Features

• High performance active direct box
• Increased dynamic range and headroom
• 48V phantom powered with switching supply
• Ideal for acoustic guitar and bass

Technical Specifications

Audio circuit type: Proprietary analog circuit with low-noise op-amp
Frequency response: 20Hz ~ 20kHz (-,+ 1.5 dB)
Dynamic range: 99dB
Noise floor: -82dB below 0dBu
Equivalent input noise: -86dBu
Maximum input: +9dBu
Phase deviation: +28 degrees at 20Hz | +1 degrees at 1kHz | -2 degrees at 20kHz
Total harmonic distortion: 0.001% @ 0 dBu
Inter-modulation distortion: 0.002% @ 0 dBu
Input impedance: 220k Ohm: 1/4" input
Output impedance: 600 Ohm - XLR output
