For a more precise control and enhancement of your sound, XU models of the MG Series come equipped with a suite of Yamaha's renowned SPX effects. Featuring high-resolution Chorus, Flanger, Distortions, Reverb and Delay, all with editable parameters, these are the same multieffects processors used on Yamaha's high-end mixing consoles, giving you the tools you need to elevate your mixes to a higher plane.

Key Features

\n
• 10-Channel Mixing Console
\n
• Max. 4 Mic / 10 Line Inputs (4 mono + 3 stereo)
\n
• 1 Stereo Bus
\n
• 1 AUX (incl. FX)
\n
• D-PRE mic preamps with an inverted Darlington circuit
\n

Technical Specs

Mixing capability On-board processors     SPX algorithm: 24 programs\nI/O   Phantom power     +48 V\nDigital I/O USB Audio Class 2.0 compliant, Sampling Frequency: Max 192 kHz, Bit Depth: 24-bit\nInput Channels    Mono[MIC/LINE]    4\nStereo[LINE]      3\nOutput Channels   STEREO OUT  2\nMONITOR OUT 1\nPHONES      1\nAUX SEND    1\nBus   Stereo: 1, AUX[FX]: 1\nInput Channel Function  PAD   26 dB (Mono)\nHPF   80 Hz, 12 dB/oct (Mono)\nCOMP  1-knob compressor Threshold: +22 dBu to -8 dBu, Ratio: 1:1 to 4:1, Output level: 0 dB to 7 dB, Attack time: approx. 25 msec, Release time: approx. 300 msec\nEQ HIGH     Gain: +15 dB/-15 dB, Frequency: 10 kHz shelving\nEQ MID      Gain: +15 dB/-15 dB, Frequency: 2.5kHz peaking\nEQ LOW      Gain: +15 dB/-15 dB, Frequency: 100 Hz shelving\nPEAK LED    LED turns on when post EQ signal reaches 3 dB below clipping\nLevel Meter 2 x 7 -segment LED meter [PEAK, +10, +6, 0, -6, -10, -20 dB]
