OVERALL SYSTEM PERFORMANCE -Frequency Response: 20Hz - 20kHz ± 3dB -Dynamic Range: 120dB (A-weighted) -Total Harmonic Distortion: <0.1% -Latency: 3msec (48kHz Sample Rate) -RF Carrier Frequency Range: Selected frequencies between 902 and 951MHz -Frequency Stability: ± 20PPM, PLL controlled -Modulation: Digital QPSK -Operating Range: Up to 300 ft. line-of-sight RECEIVER -Reception: External 7.25" (18.5cm) dual -attached antennas -Receiver Sensitivity: -94dBm -Controls: Power ON/OFF, Volume Control -Connectors: 1/4" (6.35 mm) unbalanced phone jack, Dual XLR balanced outputs -Unwanted Signal Rejection: 60dB image and spurious -Power Requirements: DC 13.5V Regulated @ 400mA -DC input: 2.1mm jack -Weight and Dimensions: 0.8lbs (363g) 8" x 6" x 1.75" (203 x 152 x 44mm) DIGITAL LT TRANSMITTER -RF Power Out: +13dBm, (50mW maximum allowed by FCC) -RF Spurious Emissions: < -50 dB -Audio Inputs: 1/8" (3.5mm) locking mini-jack, for headworn or lavalier Mic -Controls: Power switch, Audio Mute -LED Indicator: Unit on (single flash), Low Battery Alert (red) -Battery Type: 2 AA Alkaline -Battery Life: Up to 11 Hours -Weight and Dimensions: 0.15lbs (68g)/ 2.5" x 4.25" x 0.5" (64 x 108 x 13mm) OPTIONAL ACCESSORIES RMT-1KUD rack tray for rack-mounting either one or two DW-11/DW-22 receivers.
