ultra-portable pro-mixerand audio interface

TX–6 is our ultra-portable, battery-powered mixer and multi-channel audio interface. comparable to larger units, but with even more tech packed into one sturdy little machine. mix 6 stereo input channels, use tempo sync, discover the internal synthesizer and sequencer or use the built-in tuner. MFi compatibility even lets you connect to your iOS devices.

smallest of its kind.

TX–6 features a 6 channel stereo mixer with a configurable knob layout. choose to have the three-band eq at your fingertips, or customize each knob to control whichever setting you prefer. with more than meets the eye, TX–6 is packed full of features and connectivity options.

size is only half the story. battery powered   THE RECHARGEABLE BATTERY HOLDS FOR ABOUT 8 HOURS. FOR ENERGY EFFICIENCY, THE DISPLAY AUTOMATICALLY GOES TO SLEEP WHEN NOT IN USE, AND LED STRENGTH IS COMPLETELY ADJUSTABLE.     synthesizer & sequencer   TX–6 ALSO FUNCTIONS AS A PORTABLE SYNTHESIZER AND SEQUENCER WITH 4 OSCILLATOR WAVEFORMS AND 4 SYNTHESIZED DRUM SOUNDS. USE TEMPO SYNC TO STAY ON THE BEAT.     8 built-in effects   EXPLORE SEND EFFECTS LIKE REVERB, CHORUS AND DELAY, AND CREATIVE EFFECTS FREEZE, TAPE, FILTER, AND DISTORTION. EACH CHANNEL HAS A THREE-BAND EQ AND ADJUSTABLE COMPRESSOR.     quality and engineering   TX–6 IS A STURDY LITTLE MACHINE. ENCASED IN CNC ALUMINUM WITH 2K MOLDING, CUSTOM-MADE ENCODERS AND FADERS, AND CUSTOM PCB - ENGINEERED FOR PORTABILITY.     wireless connectivity   WITH BLE, YOU CAN USE TX–6 AS A WIRELESS CONTROLLER FOR OTHER BLE MIDI DEVICES OR TRIGGER AND SYNC THE INTERNAL SYNTH AND SEQUENCER FROM OTHER SOURCES.       super slimline cables   HIGH QUALITY, SLIMLINE CABLES CUSTOM-MADE FOR TX–6. THE NARROW PROFILE ALLOWS YOU TO USE ALL 6 CHANNELS AT ONCE AND MAKES FOR AN EASY PACK DOWN.
    customizable interface   WHEN YOU'RE READY FOR THE STUDIO, USE TX–6 AS A 12 CHANNEL AUDIO INTERFACE AND CONNECT TO ANY DAW OVER USB-C. MFI ALSO ALLOWS YOU TO CONNECT TO IOS DEVICES.     djmode   TURN TX–6 ON ITS SIDE AND USE IT AS A DJ MIXER. TURN CHANNEL 1 INTO A FADER TO CROSSFADE BETWEEN THE CHANNEL 5 AND 6 SO YOU CAN FADE OR CUT BETWEEN THE TWO.     6.35 + 3.5 mm output   CONNECT YOUR AUDIO OUTPUT THROUGH 3.5 MM MINI JACK OR USE THE INCLUDED AND REMOVABLE 6.35 MM JACK TO 3.5 MM MINI JACK ADAPTER.     field bags   DESIGNED TO FIT TX–6 FIELD MIXER AND CONSTRUCTED IN HEAVY DUTY FABRIC AND HARDWARE, FIELD BAGS ARE DESIGNED FOR DURABILITY, READY TO BE USED OUT IN THE FIELD.     multitrack elegance.

the first portable pro-mixer that can be used as a multi-functional 24-bit 48kHz audio interface that has an instrument tuner, built-in digital fx, synthesizer and drum machine. connect to your daw for 12 channel multitrack recordings. use the internal synth and sequencer, or control them via external midi device. with MFi you can even connect to your iOS device.

    ON THE BOTTOM SIDE OF TX–6 YOU'LL FIND THE USB-C PORT AND 6 STEREO CHANNEL INPUTS. FIELD AUDIO CABLES ARE CUSTOM MADE FOR USE WITH TX–6, THE NARROW PROFILE ALLOWS YOU TO USE ALL 6 CHANNELS AT ONCE. ON THE TOP SIDE OF TX–6 ARE THE AUX AND CUE BUTTONS, AS WELL AS THEIR INPUTS, AND A MAIN OUT. THE MAIN INCLUDE A JACK ADAPTER THAT TAKES THE INPUT FROM 3.5 MM TO 6.35 MM.     feature packed. the field system™

TX–6 is part of our ultra-portable sound recording and performance system. all battery-powered, rechargeable via usb-c and with full interconnectivity (midi and high resolution audio). compatible with iOS, macOS, and windows. it's the most powerful, highest quality, portable system in the world 'as we know it'.

TX–6 specifications TX–6 highlights

• 6 stereo input connectors
• 2 stereo output connectors
• 1 stereo headphones connector with headset microphone support
• usb audio / midi interface
• bluetooth low energy radio interface
• rechargeable battery
• 8h battery life
• 48x64 pixel monochrome display

inputs and outputs
24-bit/48kHz usb interface 3.5 mm mini jack to 6.3 mm jack headset mic input aux output connect to iPhone®, lightning cable stereo or mono for each input
dimensions and weight
90 mm (102 mm with adapter) x 62 mm x 23 mm160 g / 5.6 oz   electrical characteristics
audio inputs: impedance 10 kOhm analog gain 0 - 42 dB max level 8 dBu, 2 Vrms TLV320ADC3140 burr-brown™ SNR ~ 102 dBA
audio output (main and aux): max level 8 dBu, 2 Vrms cirrus logic masterhifi CS43131 SNR > 120 dBA
audio output (cue): max level 2 dBu, 1 Vrms cirrus logic CS47L35 SNR > 110 dBA
