Brand New

The Teletronix Story

Teletronix founder Jim Lawrence first used photocells for controlling audio gain in the early 1960s. His ingenious optical compression design was a technological breakthrough, far surpassing the stability and transparency of earlier circuits. Universal Audio founder M.T. ”Bill” Putnam later purchased this patented technology, continuing to manufacture the LA-2A for years to come.

The Teletronix Story

Teletronix founder Jim Lawrence first used photocells for controlling audio gain in the early 1960s. His ingenious optical compression design was a technological breakthrough, far surpassing the stability and transparency of earlier circuits. Universal Audio founder M.T. ”Bill” Putnam later purchased this patented technology, continuing to manufacture the LA-2A for years to come.

Technical Specifications

Input Impedance

50, 150, 250, 600 ohms

Output Load Impedance

50, 150, 250, 600 ohms

External Connections

Jones Barrier terminals and XLR connectors

Frequency Response

+0/-1 dB 30 Hz to 15kHz

Gain

40 dB ±1dB

Input Level

+16 dB maximum

Output Level

+10 dB nominal, +16 dB maximum

Distortion

Less than 0.5% THD (0.25% typical) at ±10 dBm

Noise

70 dB below +10 dBm output level

Attack Time

10 microseconds

Release Time

0.06 seconds for 50% release; 0.5 to 5 seconds for complete release

Meter

dB gain reduction and dB output

Power Requirements

35 watts, 120/240 volts, 50/60 Hz

Environmental

Maximum operating temperature 160°F

Dimensions

19" Rackmount chassis, 3U

Weight

13 lbs.
