Shure KSM137 End-Address Cardioid Condenser Microphone
Il venditore non ha impostato il costo di spedizione per Canada. Per favore contatta e chiedigli il costo della spedizione.
PrezzoC$573.16
+ spedizione
Pubblicato:più di un mese fa
Visualizzazioni:306
Salvataggi:9
Turnersville, NJ, Stati Uniti
Politica per i resi entro 14 giorni
Concediti il massimo della tranquillità con il tuo nuovo strumento
The KSM137 is an end-address condenser microphone with a single cardioid polar pattern. Designed for studio use, yet rugged enough for live applications, the KSM137 can withstand extremely high sound pressure levels (SPL). Its low self-noise and extended frequency response make it ideal for recording musical instruments. Versatile, durable, and precise, the KSM137 is an outstanding microphone for instruments ranging from percussion to wind, strings to brass, and piano to guitar.
Amazon.com
Versatile, durable, and precise, the Shure KSM137 end-address condenser microphone is an outstanding microphone for instruments ranging from percussion to wind, strings to brass, and piano to guitar. Designed for studio use, yet rugged enough for live applications, the KSM137 can withstand extremely high sound pressure levels (SPL). Its low self-noise and extended frequency response make it ideal for recording musical instruments.
Key Features
A highly consistent cardioid polar pattern
Ultra-thin, 2.5 micron, 24 karat gold-layered, low mass Mylar diaphragm for superior transient response
Class A, discrete, transformerless preamplifier for transparency, extremely fast transient response, no crossover distortion, and minimal harmonic and intermodulation distortion
Premium electronic components, including gold-plated internal and external connectors
Subsonic filter eliminates low frequency rumble (less than 17 Hz) caused by mechanical vibration Frequency response. Polar pattern.
Switchable 15 dB pad for handling extremely high sound pressure levels (SPLs)
Three-position switchable pad (0 dB, 15 dB, and 25 dB) for handling extremely high sound pressure levels (SPLs)
Three-position switchable low-frequency filter reduces background noise and counteracts proximity effect Performance Characteristics Extended frequency responseLow self-noiseExceptional reproduction of low-frequency soundsCan withstand high sound pressure levels (SPL)High output levelNo crossover distortionUniform polar responseSuperior common mode rejection and suppression of RFI (radio frequency interference)Applications Some typical applications for the KSM137 are listed below. Microphone use is a matter of personal taste and the KSM137 may be used for a variety of applications other than those listed. Acoustic instruments -- such as piano, guitar, drums, percussion, strings Wind instruments -- brass and woodwind Low frequency instruments -- such as double bass, electric bass, kick drum Overhead miking -- drums or percussion Ensembles -- choral or orchestral Room ambiance pick-up -- guitar amplifier or drums SpecificationsType: Permanently Biased Condenser Frequency Response: 20 to 20,000 Hz Directional Polar Pattern: Cardioid Output Impedance: 150 ohms (actual) Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3 Current Drain: 4.65 mA typical at 48 Vdc Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3 Weight: 3.5 ounces
Extended frequency response
Low self-noise
Exceptional reproduction of low-frequency sounds
Can withstand high sound pressure levels (SPL)
High output level
No crossover distortion
Uniform polar response
Superior common mode rejection and suppression of RFI (radio frequency interference)
Acoustic instruments -- such as piano, guitar, drums, percussion, strings
Wind instruments -- brass and woodwind
Low frequency instruments -- such as double bass, electric bass, kick drum
Overhead miking -- drums or percussion
Ensembles -- choral or orchestral
Room ambiance pick-up -- guitar amplifier or drums SpecificationsType: Permanently Biased Condenser Frequency Response: 20 to 20,000 Hz Directional Polar Pattern: Cardioid Output Impedance: 150 ohms (actual) Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3 Current Drain: 4.65 mA typical at 48 Vdc Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3 Weight: 3.5 ounces
Type: Permanently Biased Condenser
Frequency Response: 20 to 20,000 Hz
Directional Polar Pattern: Cardioid
Output Impedance: 150 ohms (actual)
Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation
Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz
Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3
Current Drain: 4.65 mA typical at 48 Vdc
Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz
Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa
Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB
Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3
Weight: 3.5 ounces
Performance Characteristics
Extended frequency response
Low self-noise
Exceptional reproduction of low-frequency sounds
Can withstand high sound pressure levels (SPL)
High output level
No crossover distortion
Uniform polar response
Superior common mode rejection and suppression of RFI (radio frequency interference)
Applications Some typical applications for the KSM137 are listed below. Microphone use is a matter of personal taste and the KSM137 may be used for a variety of applications other than those listed.
Acoustic instruments -- such as piano, guitar, drums, percussion, strings
Wind instruments -- brass and woodwind
Low frequency instruments -- such as double bass, electric bass, kick drum
Overhead miking -- drums or percussion
Ensembles -- choral or orchestral
Room ambiance pick-up -- guitar amplifier or drums SpecificationsType: Permanently Biased Condenser Frequency Response: 20 to 20,000 Hz Directional Polar Pattern: Cardioid Output Impedance: 150 ohms (actual) Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3 Current Drain: 4.65 mA typical at 48 Vdc Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3 Weight: 3.5 ounces
Type: Permanently Biased Condenser
Frequency Response: 20 to 20,000 Hz
Directional Polar Pattern: Cardioid
Output Impedance: 150 ohms (actual)
Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation
Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz
Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3
Current Drain: 4.65 mA typical at 48 Vdc
Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz
Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa
Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB
Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3
Weight: 3.5 ounces
Specifications
Type: Permanently Biased Condenser
Frequency Response: 20 to 20,000 Hz
Directional Polar Pattern: Cardioid
Output Impedance: 150 ohms (actual)
Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation
Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz
Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3
Current Drain: 4.65 mA typical at 48 Vdc
Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz
Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa
Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB
Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3
Weight: 3.5 ounces
Amazon.com
Versatile, durable, and precise, the Shure KSM137 end-address condenser microphone is an outstanding microphone for instruments ranging from percussion to wind, strings to brass, and piano to guitar. Designed for studio use, yet rugged enough for live applications, the KSM137 can withstand extremely high sound pressure levels (SPL). Its low self-noise and extended frequency response make it ideal for recording musical instruments.
Key Features
A highly consistent cardioid polar pattern
Ultra-thin, 2.5 micron, 24 karat gold-layered, low mass Mylar diaphragm for superior transient response
Class A, discrete, transformerless preamplifier for transparency, extremely fast transient response, no crossover distortion, and minimal harmonic and intermodulation distortion
Premium electronic components, including gold-plated internal and external connectors
Subsonic filter eliminates low frequency rumble (less than 17 Hz) caused by mechanical vibration Frequency response. Polar pattern.
Switchable 15 dB pad for handling extremely high sound pressure levels (SPLs)
Three-position switchable pad (0 dB, 15 dB, and 25 dB) for handling extremely high sound pressure levels (SPLs)
Three-position switchable low-frequency filter reduces background noise and counteracts proximity effect Performance Characteristics Extended frequency responseLow self-noiseExceptional reproduction of low-frequency soundsCan withstand high sound pressure levels (SPL)High output levelNo crossover distortionUniform polar responseSuperior common mode rejection and suppression of RFI (radio frequency interference)Applications Some typical applications for the KSM137 are listed below. Microphone use is a matter of personal taste and the KSM137 may be used for a variety of applications other than those listed. Acoustic instruments -- such as piano, guitar, drums, percussion, strings Wind instruments -- brass and woodwind Low frequency instruments -- such as double bass, electric bass, kick drum Overhead miking -- drums or percussion Ensembles -- choral or orchestral Room ambiance pick-up -- guitar amplifier or drums SpecificationsType: Permanently Biased Condenser Frequency Response: 20 to 20,000 Hz Directional Polar Pattern: Cardioid Output Impedance: 150 ohms (actual) Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3 Current Drain: 4.65 mA typical at 48 Vdc Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3 Weight: 3.5 ounces
Extended frequency response
Low self-noise
Exceptional reproduction of low-frequency sounds
Can withstand high sound pressure levels (SPL)
High output level
No crossover distortion
Uniform polar response
Superior common mode rejection and suppression of RFI (radio frequency interference)
Acoustic instruments -- such as piano, guitar, drums, percussion, strings
Wind instruments -- brass and woodwind
Low frequency instruments -- such as double bass, electric bass, kick drum
Overhead miking -- drums or percussion
Ensembles -- choral or orchestral
Room ambiance pick-up -- guitar amplifier or drums SpecificationsType: Permanently Biased Condenser Frequency Response: 20 to 20,000 Hz Directional Polar Pattern: Cardioid Output Impedance: 150 ohms (actual) Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3 Current Drain: 4.65 mA typical at 48 Vdc Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3 Weight: 3.5 ounces
Type: Permanently Biased Condenser
Frequency Response: 20 to 20,000 Hz
Directional Polar Pattern: Cardioid
Output Impedance: 150 ohms (actual)
Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation
Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz
Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3
Current Drain: 4.65 mA typical at 48 Vdc
Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz
Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa
Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB
Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3
Weight: 3.5 ounces
Performance Characteristics
Extended frequency response
Low self-noise
Exceptional reproduction of low-frequency sounds
Can withstand high sound pressure levels (SPL)
High output level
No crossover distortion
Uniform polar response
Superior common mode rejection and suppression of RFI (radio frequency interference)
Applications Some typical applications for the KSM137 are listed below. Microphone use is a matter of personal taste and the KSM137 may be used for a variety of applications other than those listed.
Acoustic instruments -- such as piano, guitar, drums, percussion, strings
Wind instruments -- brass and woodwind
Low frequency instruments -- such as double bass, electric bass, kick drum
Overhead miking -- drums or percussion
Ensembles -- choral or orchestral
Room ambiance pick-up -- guitar amplifier or drums SpecificationsType: Permanently Biased Condenser Frequency Response: 20 to 20,000 Hz Directional Polar Pattern: Cardioid Output Impedance: 150 ohms (actual) Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3 Current Drain: 4.65 mA typical at 48 Vdc Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3 Weight: 3.5 ounces
Type: Permanently Biased Condenser
Frequency Response: 20 to 20,000 Hz
Directional Polar Pattern: Cardioid
Output Impedance: 150 ohms (actual)
Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation
Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz
Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3
Current Drain: 4.65 mA typical at 48 Vdc
Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz
Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa
Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB
Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3
Weight: 3.5 ounces
Specifications
Type: Permanently Biased Condenser
Frequency Response: 20 to 20,000 Hz
Directional Polar Pattern: Cardioid
Output Impedance: 150 ohms (actual)
Attenuation Switch: 0 dB, 15 dB, or 25 dB attenuation
Low Frequency Response Switch: Flat; 6 db/octave below 115 Hz; -18 dB/octave below 80 Hz
Phantom Power: 48 Vdc +/- 4 Vdc (IEC26815/DIN 45 596), positive pins 2 and 3
Current Drain: 4.65 mA typical at 48 Vdc
Common Mode Rejection: ≥50 dB, 20 Hz to 20 kHz
Sensitivity (typical, at 1000 Hz; 1 Pa = 94 dB SPL): -37 dBV/Pa
Selfnoise (typical, equivalent SPL; A-weighted, IEC 651): 14 dB
Polarity: Positive pressure on diaphragm produces positive voltage on output pin 2 relative to pin 3
Weight: 3.5 ounces
| Condizione | Nuovo (Nuovo) Gli articoli "Nuovi” sono venduti da un rivenditore autorizzato o dal produttore originale e comprendono l’imballo originale.Scopri di più |
|---|---|
| Marchio | |
| Modello |
|
| Categorie | |
| Tipo di microfono |
|
| Con cavo/senza cavo |
|
| Elettronica |
|
| Figura polare |
|
Le informazioni sulla sicurezza del prodotto sono disponibili qui.
