The smooth natural feel of an acoustic grand piano in a lightweight but elegant keyboard, the Nord Grand is a new approach to the stage piano series from Nord. The premium weighted keybed with advanced triple sensors is designed to capture the movements of hammer play with exceptional precision for a smooth, dynamic touch. Whether playing percussively or pianissimo, the well balanced and responsive triple sensor Kawai Responsive keybed provides extraordinary control with fluent repetitions and retriggering without lifting the key completely. An Ivory Touch surface gives the keybed an optimal feel and authenticity, while dedicated knobs and buttons control all essential functions required in a live performance situation to create Layers and Splits or adding effects on the fly. Nord Grand features seven Split points and Split Point Crossfades for smooth transitions between split zones, all indicated with LED lights. Advanced section samples—Piano, Sample Synth, and Effect—allow players to experience a wide range of professional quality Nord sample libraries for broadening their sound without loosing the Grand style.

Includes

• Nord Triple Pedal
• User Manual
• Power cord
• Dust cover

Features

• 88-note Kawai Hammer Action with advanced triple sensors
• Ivory touch keys with Soft Release and Advanced Strong Resonance
• Seamless Transitions when changing programs
• Layer and Split with Split Point crossfades
• OLED display for excellent overview
• Support for Nord Piano Monitor

Specifications

• OLED Display
• 6 types - Grand, Upright, Electric Pianos, Clavinet, Digital and Misc.
• 46 Voice Polyphony
• Approx. 2GB dedicated to the Nord Piano Library
• Pan, Tremolo, Wah and Ring Modulator
• 2 Audio outputs L & R - ¼", 6.35mm jacks, unbalanced
• Nord Grand: 1286mm (50.7"), 168mm (6.6"), 387mm (15,2")
• Nord Grand: 20.9kg (46.0lbs)
• Seamless Transitions
• Each category can contain up to 20 different models.
• Amp envelope with Attack and Decay/Release
• Approx. 512MB dedicated to the Nord Sample Library 3.0
• Three selectable depths for the Pan and Tremolo, rate controlled with the Effect 1 Rate knob
• 1 Monitor input - 1/8", 3.5mm stereo jack
• Nord Triple Pedal: 264mm (10.4"), 224mm (8.8"), 70mm (2.8")
• Pedal: 2kg (4.4lbs)
• Split Point Crossfades
• 120 Voice Polyphony (stereo/mono pianos)
• Selectable velocity sensitive low pass filter and dynamic range
• Tremolo, Pan, Ring-Mod and Wah can be controlled with Control Pedal
• 1 Headphone output - ¼", 6.35mm stereo jack
• 16 banks with 25 programs - 400 locations
• Piano Timbre/EQ settings (Soft, Mid, Bright) with dedicated Electric Piano filters (Soft, Mid, Bright, Dyno 1 and Dyno 2).
• Octave transpose: -1/+1 (-6/+6 in Split mode, depending on Split position)
• • Phaser 1, Phaser 2, Flanger, Chorus 1, Chorus 2 and Vibe
• 1 Piano pedal input - ¼", 6.35mm jack. Use the included Nord Triple Pedal or a momentary pedal, like e.g, Roland DP-2, DP-6, Yamaha FC-4, FC-5, Fatar VFP1-25 etc
• Organize functionality for programs
• Advanced String Resonance (Generation 2) - adjustable amount
• Volume controllable with Volume Pedal (not included)
• • Two selectable depths for each effect
• 1 Volume Pedal input - ¼", 6.35mm TRS stereo jack. Use a Control/Expression pedal like e.g. Yamaha FC-7, Roland EV-5 etc.
• Live Mode - 5 Live programs
• Selectable Soft Release for Grand, Upright, Electric Pianos and Harpsichord
• • Comp/Amp - three amp/speaker simulations, Tube Overdrive
• MIDI In, MIDI Out - 5 pin DIN connectors
• Global Transpose: +/- 6 semitones
• Selectable Pedal Noise for Grand, Upright and Electric Pianos 1 - adjustable amount
• • Drive/Compression amount controlled with the Drive knob
• USB - type B connector - for transferring sounds and USB MIDI
• Program Transpose: +/- 6 semitones
• Octave transpose: -1/+1 (-6/+6 in Split mode, depending on Split position)
• • Three band EQ, with sweepable mid. +/- 15dB gain/attenuation
• IEC C14 power connector
• Fine-tune: +/- 50 Cents
• • Dedicated Reverb with Room, Stage and Hall algorithms, each with an additional Bright mode
• Kbd Touch: 3 velocity response curves
• • Dedicated Delay Effect - Rate, Amount and Tap-tempo function
• 88-note Kawai Responsive Hammer keybed with Advanced Triple Sensors
• Split functionality with selectable split point and LED indication
• Optional Split crossfade
• Layer functionality
• Panel Lock option
• Mono Output option
• Dynamic Sustain Pedal action with the included Nord Triple Pedal
• USB-MIDI
• Free OS updates
