Tio1608-D2  YAMAHA

 Dante Rackmount Cat5e I/O Digital Stagebox

The Tio1608-D2 is a 96kHz capable Dante-equipped I/O rack with 16 microphone/ line inputs and 8 line outputs. A stage box system can be used with DM3-D and other Yamaha digital consoles. The D2 version features low latency & 96kHz converters. Not only can the Yamaha digital consoles control Tio1608-D2's internal preamp, the Auto Setup feature enables setup with minimal effort.


Features:

• Renowned Yamaha sound quality with 96kHz sample rate

• 3U size, 16 inputs and 8 outputs.

• Dante network protocol contributes to greater system scalability and flexibility

• Supports QUICK CONFIG Mode for DM3 and TF series

• Automatic digital-stage compensation for analog gain changes (CL/QL series only)

• Recallable D-PRE preamplifiers"

Specifications:

• Sampling frequency rate: External 44.1kHz, 48kHz, 88.2kHz, 96kHz

• Buses: 1 Stereo, 6 Mix, 2 FX, 2 Matrix (Input to Matrix supported)

• Signal delay: Less than 1.3ms INPUT to OUTPUT, connect with DM3, Dante Receive Latency set to 0.25ms (one way), Fs=96kHz; Less than 2.6ms INPUT to OUTPUT, connect with DM3, Dante Receive

• Latency set to 0.25ms (one way), Fs=48kHzTotal harmonic distortion: Less than 0.2% +4 dBu @ 20Hz-20kHz into 600Ω, Gain= +66 dB / Less than 0.05% +4 dBU @ 20Hz-20kHz into 600Ω, Gain= -6 dB, INPUT to OUTPUT, Fs    = 88.2kHz, 96kHz; Less than 0.1% +4 dBu @ 20Hz-20kHz into 600Ω, Gain=+66 dB / Less than 0.05% +4 dBU @ 20Hz-20kHz into 600Ω, Gain=-6 dB, INPUT to OUTPUT, Fs= 44.1kHz, 48kHz *Measured with a -18 dB/octave filter @ 80kHzFrequency response: +0.5, -1.5 dB 20Hz-20kHz, refer to the nominal output level @ 1kHz, INPUT to E14

• Dynamic range: 108 dB, INPUT to OUTPUT, Gain=-6 dB / 110 dB, DA Converter, Fs 96kHz; 108 dB, INPUT to OUTPUT, Gain=-6 dB / 112 dB, DA Converter, Fs 48kHz

• Equivalent input noise: -128 dBu, Gain=+66 dB, Fs 96kHz, 48kHz *Measured with A-weighting filter

•  Residual output noise: -86 dBu, Fs 96kHz / -88 dBu, Fs 48kHz, ST main off *Measured with A-weighting filter

• Crosstalk: -100 dB, adjacent INPUT/OUTPUT channels, Input Gain = -6 dB *Measured with a -30 dB/octave filter @22kHz

• Heat dissipation: 100-240V, 50/60Hz, 43.5kcal/h

• Power requirements: 50W

• Dimensions: 18.9”x 3.5”x 14.4”

• Net weight: 12.6 lbs

SALE: $1549.99

FREE S&H in continental US (e-mail for international / offshore USA rates)
