Shure P3T Single-Channel Half-Rack Wireless Transmitter for PSM 300 In-Ear Monitor System - J13 566-590 MHZ
This seller has not set a shipping cost for Lithuania. Please contact them to ask about shipping.
14-Day Return Policy
Enjoy peace of mind with your new gear
Our users rate Reverb
Dependable wireless transmission and 24-bit digital audio combine in the P3T Wireless Transmitter to deliver a superior personal monitoring mix for every performance. Send two channels of audio to a bodypack receiver up to 300 feet (90 m) away, with patented Audio Reference Companding to ensure transparent sound quality with no artifacts or dropouts. Setup is a snap with the one-touch IR sync that instantly links transmitter to receiver. Rear-panel ¼” TRS balanced inputs and loop outputs provide versatile connectivity to audio sources and other P3T units.
Includes- P3T Half-Rack Single-Channel Wireless Transmitter
- Rackmount and hardware kits
- Detachable ¼-Wave Antenna
- BNC Cable
- BNC Bulkhead Adapter
- Power Supply
- User Guide
- Sends a stereo or mono mix wirelessly to performers onstage
- Detailed, 24-bit digital audio
- Rock-solid analog wireless connection over a 300 foot (90 meter) range
- One-touch IR sync instantly links transmitter to bodypack receiver
- High-contrast LCD screen with audio metering
- Selectable line/aux level
- ¼" (6.3 mm) TRS balanced inputs and loop outputs
- Detachable ¼-wave antenna
- Rack hardware kit included
- RF Carrier Range: 488 – 937.5 MHz (Note: varies by region)
- Compatible Freqeuncies Per Band: Up to 15
- Tuning Bandwidth: 24 MHz maximum (Note: varies by region)
- Operating Range: 300ft (90m)
- Audio Frequency Response: 38 Hz – 15 kHz
- Signal-to-Noise Ratio: 90 dB (typical)
- Total Harmonic Distortion:< 0.5% (typical) (ref. +/- 34 kHz deviation @ 1 kHz)
- Companding: Patented Shure Audio Reference Companding
- Spurious Rejection: >80 dB (typical)
- Frequency Stability: +/- 2.5 ppm
- MPX Pilot Tone: 19 kHz (+/- 1 Hz)
- Modulation: FM, MPX Stereo (ref. +/- 34 kHz deviation @ 1 kHz)
- Operating Temperature: 0° F to 145° F (-18° C to +63° C)
- RF Output Power: 10, 20, 30 mW (Note: varies by region)
- RF Output Impedance: 50 Ohms (typical)
- Net Weight: 27.6oz. (783 g)
- Dimensions (H x W x D): 1.7" x 7.8" x 6.8" (43 x 198 x172mm)
- Power Requirements: 12 – 15 V DC, 260 mA maximum
| Condition | Brand New (New) Brand New items are sold by an authorized dealer or original builder and include all original packaging.Learn more |
|---|---|
| Brand | |
| Model |
|
| Finish |
|
