Iron Maiden is one of the most successful and influential metal bands ever, and Adrian Smith's molten yet melodic guitar work has long been a driving force behind their distinctive and dynamic sound. With timeless songwriting and thrilling live performances, Maiden continues to record, tour internationally and rock stadiums everywhere with electrifying prowess and unwavering heavy metal passion.

Jackson pays tribute to the legendary axeman with the X Series Signature Adrian Smith SDXM model. Offered in an affordable price range, the SDXM features a poplar San Dimas  body and a bolt-on maple neck with graphite-reinforcement rods that refuse to budge, no matter how much environmental stress it's exposed to. Its 12"-16" compound radius maple fingerboard with 22 jumbo frets and black dot inlays is the perfect launching pad for rapid-fire riffing or complex chords.

The SDXM packs a Jackson high-output humbucker in the bridge position and Jackson single-coil pickups in the neck and middle positions. The humbucking pickup was painstakingly voiced for full, rich tone while providing maximum overdrive and sustain, whereas the single-coil middle and neck pickups deliver that unmistakable Strat  snap. A five-way blade selector switch with single volume and tone controls open up endless tonal possibilities, while the Floyd Rose  Special double-locking tremolo system keeps the guitar in tune through any and all abuse you throw its way.

12"- 16" Compound Radius Maple Fingerboard

Jackson pioneered the use of the innovative 12"-16" compound radius design, in which the maple fingerboard gradually flattens toward the heel from its more rounded profile at the nut. This makes for comfortable and natural-feeling chording and riffing near the nut, with optimal shred articulation and bending nearer the heel.

HSS Confirguration : Jackson High-Output Humbucking (Bridge) & Jackson Single-Coil (Middle & Neck)

An atypical configuration for Jackson, this guitar features a humbucker in the bridge position and single-coil pickups in the neck and mid positions. The Jackson high-output humbucking pickup was painstakingly voiced for full, rich tone while providing maximum overdrive and sustain. The Jackson single-coil middle and neck pickups deliver that tried-and-true Strat sound.

Features

• 25.5" scale length
• Poplar San Dimas body
• Bolt-on maple neck with graphite reinforcement
• 12"-16" compound radius maple fingerboard with 22 jumbo frets and black dot inlays
• Jackson high-output humbucking bridge pickup and Jackson single-coil neck and middle pickups
• Five-way blade switch, single volume control and single tone control
• Floyd Rose Special double-locking tremolo bridge system
• Available in Snow White with white pickguard, black hardware and licensed Fender Strat  headstock

Body

• Body Material : Poplar
• Body Finish : Gloss
• Body Shape : San Dimas

Neck

• Number Of Strings : 6
• Neck Material : Maple
• Neck Construction : Bolt-On with Graphite Reinforcement
• Neck Finish : Satin
• Scale Length : 25.5" (64.77 cm)
• Fingerboard Material : Maple
• Fingerboard Radius : 12"-16" Compound Radius (304.8 mm to 406.4 mm)
• Number Of Frets : 22
• Fret Size : Jumbo
• Nut Material : Floyd Rose Locking
• Nut Width : 1.6875" (42.86 mm)
• Position Inlays : Black Dot
• Truss Rod : Dual-Action
• Truss Rod Nut : Truss Rod Adjustment at Nut

Electronics

• Bridge Pickup : Jackson High-Output Humbucking
• Middle Pickup : Jackson Single-Coil
• Neck Pickup : Jackson Single-Coil
• Controls : Volume, Tone
• Switching : 5-Position Blade: Position 1. Bridge Pickup, Position 2. Bridge and Middle Pickup, Position 3. Middle Pickup, Position 4. Middle and Neck Pickup,
• Position 5. Neck Pickup
• Configuration : HSS

Hardware

• Bridge : Floyd Rose Special Double-Locking Tremolo (Recessed)
• Hardware Finish : Black
• Tuning Machines : Jackson Sealed Die-Cast
• Pickguard : 1-Ply Black
• Control Knobs : Dome-Style
• Switch Tip : Black
• Neck Plate : Jackson

Miscellaneous

• Strings : Nickel Plated Steel (.009-.042 Gauges)
