A very successful and versatile 10”, the Falcon 10 adds a new dimension of openness to the classic, fat and warm tone of its 12” version. The seamed cone membrane delivers an unexpected bass response for its 10” size and it is balanced perfectly with its sweet, yet cutting and present high end.

Guitarist Description: Warm, straightforward tone with a pronounced low end. When presented with overdrive distortion, it presents some mean fuzz.

• Lows: Tight/Fat
• Mids: Firm
• Highs: Smooth
• Overdrive: Crunchy

Product Measurements

Diameter: 10 in.
Voice Coil Diameter: 1.25 in.
Depth: 3.8779 in.
Outer Diameter: 10.1969 in.
Inner Diameter: 9.0944 in.
Mounting Hole Bolt Circle Diameter: 9.6456 in.
Magnet Assembly Diameter: 4.0157 in.
Mounting Hole Diameter: 0.2559 in.
Nominal Overall Diameter: 259.00 mm
Nominal Voice Coil Diameter: 32.00 mm
Flux Density: 1.10 T
Voice Coil Winding Depth: 9.00 mm
Magnetic Gap Depth: 6.00 mm
Magnet Type: Ferrite
Voice Coil Winding Type: Copper
Voice Coil Former: Epotex
Cone Material: Paper
Surround Material: Integrated Paper
Dust Dome Material: Non-treated Cloth
Basket Material: Pressed Sheet Steel
Surround Treatment: Yes
Voice Coil DC Resistance (Re): 12.32 Ω
Resonance Frequency (ƒS): 119.00 Hz
Mechanical Q Factor (QMS): 17.27
Total Q Factor (QTS): 2.06
Mechanical Moving Mass (MMS): 18.90 g
Mechanical Compliance (CMS): 95.00 µm/N
Force Factor (BxL): 8.61 Wb/m
Equivalent Acoustic Volume (VAS): 14.60 liters
Linear Displacement, maximum (XMAX): 1.50 mm
Reference Efficiency (nO): 1.01 %
Diaphragm Area (SD): 330.10 cm2
Losses Electrical Resistance (RES): 90.90 Ω
Voice Coil Inductance @ 1 kHZ (LE): 1.02 mH
Rated Power: 40.00 W
Musical Power: 80.00 W
Sensitivity @ 1W, 1m: 93.40 dB
