Elektron Outbox 8 Multi Output Interface

8-Channel Audio and CV Breakout Box

• 8 freely configurable outputs for audio and CV
• Individual output of audio tracks and submixes from compatible devices
• USB MIDI to CV conversion for controlling CV-compatible devices
• Can be used as a USB audio interface with eight outputs for computers, tablets and smartphones
• Compatible with Elektron Overbridge-enabled devices
• Supports USB Class-Compliant MIDI and audio devices
• Set up directly on compatible Elektron devices or, alternatively, via a browser-based web editor
• CV signal types: Grounded, Pitch V/Oct, Pitch Hz/V, Value Lin, Trig, Gate and Clock
• 8 DC-coupled audio and CV outputs: 6.3 mm TRS jack
• D/A converter: 48 kHz 32 Bit
• CV output range: +/- 5 V
• 1 USB-C power supply
• 1 USB 2.0 USB-C data port with USB Power Delivery and dual-role data and power supply
• LED status indicator
• Power supply: 5 V / 0.5 A / 2.5 W or higher (not included)
• Dimensions (W x D x H): 176 x 90 x 28 mm
• Weight: 0.35 kg
• Includes USB-C to USB-A cable
