JS3CR JS

Made in Japan

Maple neck

The Maple neck provides stability and bright tonal character.

Rosewood fretboard

Rosewood fretboard provides a well-balanced solid tone with a focused mid range.

Medium frets with Prestige fret edge treatment

Medium sized frets enhance the accuracy of your notes. Prestige Fret Edge Treatment guarantees effortlessly fast playing.

DiMarzio® PAF Pro® / DiMarzio® Satchur8™ pickups

The DiMarzio® PAF Pro® pickups produce an open and clean low end with a carefully tweaked treble side that helps cut through the mix. DiMarzio® Satchur8™ pickup fully supports Joe's versatile playing style and massive sound.

Gotoh® machine heads

Gotoh® machine heads provide superior precision, a smooth feel, and excellent tuning accuracy.

Edge tremolo

The masterpiece Edge bridge offers exceptional tuning stability, precise intonation adjustment, and playing comfort.

High-Pass filter on volume control

A high pass filter on the volume pot maintains highs at low volumes.

Coil-tap switch on tone control (push/pull)

The push/pull coil tap adds sound and tonal variations for pickups.

Chrome Finish Neck Dimensions

Scale : 648mm//25.5"

Width at NUT (a): 42.8mm

Width at 21F (b): 56.4mm

Thickness at 1F (c): 20mm

Thickness at 12F (d): 22.3mm

Radius : 250mmR

Switching System

This guitar has two different wiring configurations, one with the tone knob in the up position and another with it in the down position.

When the volume knob is pulled up, the Hi-pass filter is on.

When the tone knob is down and the pickup selector switch is in neck position, the neck pickup is selected.

When the switch is in center position, both the neck and bridge pickups are selected.

When the switch is in bridge position, the bridge pickup is selected.

When the tone knob is pulled up and the pickup selector switch is in neck position, the bridge side of the neck pickup is selected.

When the switch is in center position, the bridge side of the neck pickup and the neck side of the bridge pickup are selected.

When the switch is in bridge position, the neck side of the bridge pickup is selected.

Controls

With the guitar held in the playing position, there are two knobs near the lower bout of the guitar.

The knob closest to the end of the body is the tone knob, and the knob closer to the neck is the volume knob.

The tone knob also works as a coil tap switch, and the volume knob also works as a high pass filter switch.

There is a three-way pickup selector switch between these two knobs.
