Here is a Kay Fuzz Tone circuit from 1969, a modification of the Univox Superfuzz. It is the first pedal in the series to have an expression input and a JHS mode, which, in addition to silicon diode clipping, adds parallel germanium diode clipping and can be controlled via expression. The sound is fat, creamy and clearly a legendary fuzz sound.
Electric Guitar Effect Pedals
Fuzz
The Legends Of Fuzz Series
Based on the Kay Fuzz Tone
The original is one of The Edge's most popular pedals
Switchable JHS mode increases fuzz intensity with brighter mids
True bypass
Volume and frequency controls
Mode change
Bypass footswitch
Status LED
Metal housing
Input and output: 6.3 mm mono jack
Power supply via 9 V battery or 9 V DC power supply (2.1 x 5.5 mm barrel plug, polarity (-) inside, suitable mains adapter: Art.409939, not included in delivery)
Power consumption: 4 mA
Dimensions (L x W x H): 144 x 92 x 51 mm
Weight approx. 380 g
