A Shortcut for Atmospheric Processing

Iroi is a compact, 18 HP stereo effects powerhouse designed to turn any external signal into a deep, evolving soundscape. It inherits the sophisticated processing chain of its predecessor, Oneiroi. Combines a unique signal chain composed of a multimode filter, a VCA, a unique character resonator, a versatile delay, and an experimental Reverb. The filter – VCA act like a block that can be placed at any point on the signal chain

ONEIROI SOUL

Iroi is a chopped-down version of oneiroi with a new mapping structure; It allows you to craft ethereal textures from your own sound sources. A module built to summon deep, character-filled sonic dimensions to your existing setup.

Stereo Multi-Mode Filter

Transform any external signal through his unique stereo multi-mode filter. Choose between Low-pass, Hi-pass, Band-Pass, and Comb Filter and place it at any point of the signal chain. A fast-response digital VCA follows the filter to allow the user to create complete Synth voices just by adding their favorite sound sources and envelopes.

From subtle harmonic mangling to radical sonic alchemy, all within 18 HP.

Experimental Reverb

Immerse your sounds in lush, expansive reverbs and gritty Lo-Fi echoes. The Spacetime control is able to transfer smoothly from short to long to invert reverbs to bloom into hauntingly beautiful atmospheres.

Advanced Mapping System

The IROI Modulation system allows you to randomize, modulate, and CV control all knobs, each one to your preferred amount. Just hold the MAP button while turning the desired parameter, and you are ready to go.

Resonance and character.

Infuse your signals with metallic textures and organic resonance. An ear-tuned resonator designed to add physical presence and harmonic depth to any sound.

Internal Modulation System

Easily create movement within your patch by mapping the internal LFO, or let the incoming audio modulate itself using the envelope follower. Map precisely one of the seven wave shapes to the desired parameter and then control all the mappings at the same time with the Mod Level control. A compact gateway to deep, evolving soundscapes that turn simple inputs into cinematic journeys.

FEATURES

• Stereo External input
• Multimode filter: low-pass, band-pass, high-pass, and comb filter.
• 3-band resonator
• 2-tap echo
• Reverb with macro control for size, filtering, and direction
• CV Control with attenuators on most parameters
• Various types of self-modulation with configurable routing and control over level and speed
• External synchronization via sync input

• Powerful randomizer with four different targets with undo/redo

SPECS

• Current needs: +12V: 175mA, -12V: 45mA
• Width: 18 HP
• Depth: 27 mm (including power connector)
• Aluminium, Matt Anode front panel
• Designed and assembled in Barcelona
