When professional sound needs to travel light without sacrificing impact, the RCF EVOX JMIX-9 system delivers a compelling blend of power, clarity and control in a refined column array format. Built around a true three-way design, it pairs a wide-dispersion high-frequency section, articulate midrange array and a deep-reaching 12" subwoofer with an integrated digital mixer—making it a complete, self-contained PA for performers and events on the move. With 2100W of Class-D amplification, up to 130dB of maximum SPL and a low-profile enclosure that blends into virtually any environment, the JMIX-9 is engineered for DJs, bands, presenters and venues that demand professional results from a compact system.

True Three-Way Array With Coherent, Point-Source Clarity

At the core of the EVOX JMIX-9 is a true three-way acoustic design that delivers a natural, balanced sound field across the audience area. A 1.75" neodymium compression driver loaded onto RCF’s 120° × 40° True Resistive Waveguide provides wide, consistent high-frequency coverage, while six 3" full-range neodymium drivers handle the critical midrange with precision and punch. This alignment creates a unified acoustic center that radiates like a single point source, resulting in exceptional intelligibility, smooth phase response and even coverage from front row to back.

Deep, Controlled Low End With Touring-Grade Power

Low-frequency duties are handled by a high-power 12" RCF woofer housed in a bass-reflex enclosure, delivering tight, controlled lows that support everything from spoken word to bass-heavy music. Driven by a dual-channel Class-D amplifier rated at 2100W peak, the system maintains headroom and clarity even at higher output levels. Integrated DSP with FiRPHASE processing ensures phase-accurate response and musical transparency, helping vocals stay clear and instruments remain defined at any volume.

Integrated 8-Channel Digital Mixer With Onboard DSP

The EVOX JMIX-9 stands apart with its built-in 8-channel true-stereo digital mixer, eliminating the need for external mixing gear in many setups. Four studio-grade mic/line inputs with THAT preamps offer individual 48V phantom power, while onboard processing includes high-pass filters, one-knob compression and 3-band EQ on input channels. Reverb effects, AUX sends, and an 8-band EQ on the outputs provide comprehensive control, making it easy to tailor the system for different performers, rooms and applications.

Wireless Control and Bluetooth Streaming for Modern Workflows

Built-in Bluetooth streaming allows quick playback from mobile devices, while Bluetooth Low Energy connectivity enables full system control via the intuitive JMixRemote app. From a smartphone or tablet, users can adjust levels, EQ, dynamics and effects without touching the hardware—ideal for performers mixing themselves from the stage or engineers tuning the system from the room. A 2.4" color touch display and ergonomic encoders on the unit itself provide fast, hands-on access when needed.

A Complete, Professional PA Solution That’s Easy to Deploy

Finished in a sleek composite cabinet available in black or white, the EVOX JMIX-9 is designed to disappear visually while delivering unmistakable sonic presence. Dual-height configuration, a quick-fit pole mount and an included padded carrying bag make transport and setup straightforward, even for solo operators. Whether you’re running a live band, DJ set, corporate presentation or mobile event, the RCF EVOX JMIX-9 offers a reliable, great-sounding all-in-one PA solution that’s ready to perform wherever the gig takes you.

• True three-way column array projects a focused, natural stereo image across the venue
• 2100W Class-D amp with 130dB max SPL handles high-output live sets without clipping
• 8-channel digital mixer features per-channel EQ, compression and stereo reverb for flexible control
• Bluetooth 5.3 streaming lets you play backing tracks or reference mixes wirelessly
• 1.75" neodymium compression driver and six 3" full-range drivers deliver clear mids and highs
• 12" bass reflex woofer extends low-end down to 40Hz for full-band mixes
• JMixRemote app offers wireless mixer control from anywhere in the room
• Individual 48V phantom power on four channels supports condenser mics and active DIs
• True stereo mix output lets you link two systems for wide coverage
• 2.4" color touch display speeds up system setup and recall on stage

Specs General

• Product type: Powered column PA system with digital mixer
• Series: EVOX J
• Amp type: Class-D

Audio performance

• Frequency range: 40Hz–20000Hz
• Maximum SPL: 130dB
• Horizontal coverage: 120º
• Vertical coverage: 40º

Speaker configuration

• HF driver: 0.75" neodymium compression driver with 1.75" voice coil
• Midrange drivers: 6 × 3.0" neodymium full range drivers with 1.0" voice coil
• LF driver: 12" woofer with 2.5" voice coil

Power handling and supply

• Total power: 2100W peak
• HF power: 700W peak
• LF power: 1400W peak
• Cooling: Convection cooling

DSP and processing

• DSP sample rate: 48kHz
• DSP resolution: 32-bit
• AD and DA conversion: 32-bit
• AD dynamic range: 120dB
• DA dynamic range: 118dB
• Crossover frequencies: 160Hz and 1600Hz
• Limiter: Soft limiter

Mixer

• Mixer channels: 8 channel digital mixer
• Mic inputs: 4 mic and line combo inputs with THAT preamps
• Mic gain range: 36dB remote controllable
• Phantom power: 48V individually selectable on channels 1 to 4
• Stereo line inputs: TRS and 3.5 mm mini jack
• Bluetooth audio: Bluetooth 5.3 streaming input
• Input processing: High pass filter 20Hz–400Hz 3 band EQ and one knob compressor on channels 1 to 4
• Internal effects: Digital stereo reverb with per channel send and ducker
• Output processing: 8 band parametric EQ on main and AUX outputs

User interface

• Display: 2.4" color display with capacitive touch
• Controls: Dual function endless encoders and programmable pushbuttons
• Remote control: JMixRemote app via Bluetooth Low Energy

Connectivity

• Main output: Balanced XLR
• Aux output: Balanced XLR
• Headphone output: 3.5 mm mini jack
• USB port: USB C for charging and firmware update
• Power connectors: PowerCON TRUE1 input and output

Construction

• Cabinet material: PP composite
• Grille: Steel
• Handles: One top handle
• Pole mount: Quick fit socket
• Color options: Black and white

Dimensions and weight

• Height: 81.89"
• Width: 13.78"
• Depth: 18.21"
• Weight: 58.42 lb.

Included accessories

• Accessories: Top speaker padded carrying bag
