The Hermod+ sequencer by Squarp instruments is an advanced 16-track Eurorack sequencer and MIDI-to-CV interface. Combining the creative power of a DAW with hardware modular control, it features 8 CV/Gate tracks and 8 MIDI tracks, an intuitive polyphonic piano roll, and real-time effects like LFOs and arpeggiators.YouTube·Stazma +3Core Features

• Track Layout: 8 CV/Gate tracks (compatible with V/oct, 1.2V/oct, and Hz/V) and 8 MIDI tracks.wrdtunes.com
• High Resolution: Recordings are captured at 96ppqn, ensuring flawless playback accuracy.wrdtunes.com +1
• 4-Mode Interface:
• • Step Mode: Polyphonic piano roll editing with row-by-row adjustments and advanced parameter locks.
  • Effects Mode: Up to 8 real-time effects (e.g., Delay, Chance, Swing, Arpeggiator, Ratchet).
  • Track Mode: Controls mutes, voices, and track layouts (mono, poly, or unison).
  • Seq Mode: Sequence chaining (up to 64 entries) for song building and live performance arrangements. YouTube·Squarp instruments +6
• Connectivity:
• • 8 x 16-bit CV/Gate outputs and 4 x 16-bit CV inputs for modulation and clock synchronization.
  • MIDI In/Out (TRS 3.5mm) and Dual USB (Host and Device) ports. ModularGrid +1

Hardware Specs

• Size & Form Factor: 26 HP Eurorack format, 20mm deep.
• Power: +12V: 400mA, -12V: 20mA.
• Expandability: Fully compatible with the Squarp Instruments xp32 expander, which adds an additional 32 CV/Gate outputs.
