LINDELL AUDIO LIN76 DETAILS

Craft your sound with the flexibility of the LINDELL LiN76, featuring variable attack and release times for dynamic control at your fingertips.

The LiN76 has been carefully designed to recreate the timbres of nuances of vintage-era '76-style FET compressors.

The most classic and respected sounds of dynamic processors live on in the LiN76, as well as the infamous "all-button" mode made famous by British recording engineers throughout the 1970's - A sound that's still popular today.

Features:

Instant vintage-vibe dynamics processing

USA-made transformers

4:1, 8:1, 12:1, 20:1, and "All-button" compression ratio modes

Vintage-style VU for monitoring

Variable attack and release times, with ultra-fast attack options

Balanced input and output

Specifications:

Attack Continuously variable 20uS to 800uS

Release Continuously variable 50mS to 1200mS

Ratio Pushbutton selected 4:1, 8:1, 12:1, 20:1 and any combination

Voltage 12VAC

AC Mains Input 100V-240V depending on supplied

Dimensions Width 438mm (19")

Height 88mm (2U)

Depth 250mm

Weight 8kg

Some notes on Attack and Release: Compressor control schemes can vary significantly. On the LiN76 we've chosen "left is less, right is more."

Turn the Attack knob to the left for faster attack times and to the right for slower, with a 20uS to 800uS range.

Turn the Release knob to the left for faster release times and to the right for slower, with a 50mS to 1200mS range.

The LINDELL LiN76 doesn't just process dynamics; it breathes life into your music, thanks to its authentic vintage vibe and modern precision.
