Type 3-speed, fully manual operation

MotorDC servo motor

Drive MethodDirect driveSpeeds33-1/3 RPM, 45 RPM, 78 RPM

Turntable PlatterDie-cast aluminum

Starting Torque>1.0 kgf.cm

Braking SystemElectronic brake

Wow and Flutter<0.2% (WTD) @ 3 kHz (JIS)

Signal-to-Noise Ratio>50 dB

Output LevelPre-amp "PHONO": 4 mV nominal at 1 kHz, 5 cm/sec

Pre-amp "LINE": 240 mV nominal at 1 kHz, 5 cm/sec

Phono Pre-Amp Gain36 dB nominal, RIAA equalized

USB FunctionA/D, D/A – 16-bit/44.1 kHz or 48 kHz USB selectable; Computer interface – USB 1.1 Compliant Windows 7 or above, or MAC OS X or above

Power Supply Requirements100 to 240 V, 50/60 Hz, 1.5A Max.

Dimensions452.0 mm (17.80") W x 352.0 mm (13.86") D x 141.6 mm (5.57") H

Weight8 kg (17.6 lbs.), without dust cover

Accessories IncludedAT-VM95E phono cartridge; AT-HS6 headshell; 1.9 m (6.2') USB cable; dual RCA (male) to dual RCA (male) cable with ground wire; counterweight; felt mat; dust cover; 45 RPM adapter; plug-type stylus target light

NotesTonearm type: Balanced S-shaped tonearm with detachable headshell Effective arm length: 230.5 mm Overhang: 16 mm Tracking error angle: Less than 3 degrees Applicable cartridge weight: 3.5-8.5 g Anti-skating range: 0-4 g Replacement Stylus: AT-VMN95E USB operation system requirements PC or Mac with an available USB port (USB1.1 or higher) Windows 7 or above, or Mac OS X or above
