Product Features:

• High quality dual channel preamp
• Independent 3 band EQ, Gain and Volume controls for each channel
• Speaker cabinet simulation on/off
• 2 different modes for footswitch operation. On/Off or channel A/B


Connection:

• 1.DCIN:
• Connect a DC 9V 300mA centre pin negative power supply
• 2.INPUT:
• Connect your instrument directly or the output of your pre, pre-amp effects like Overdrive, distortion, etc.
• 3.OUTPUT:
• Connect to a power amp or your amplifier's effects return.(Highly recommend using a tube amplifier)
• Different power amplifiers will affect the outcome of the final tone.You can also connect directly to a sound card and activate the speaker cab simulation for recording purposes.
•
• Note: You can connect your "fx loop" effects, like modulation and time based effects, in between the MOOER preamps output and the input of the power amp (fx return)


Specifications:

• Modes:Delay and reverb effects with tap tempo functionality.
• Input:1/4" mono audio jack.(Impedance: 1 meg Ohms)
• Output:1/4" mono audio jack(Impedance: 100 Ohms)
• Power requirements: AC adapter 9V DC , center negative.(Highly recommend to use Mooer Micro Power.)
• Current Draw:300mA
• Package Size: 12 * 7* 6cm/ 4.7 * 2.8 * 2.4in
• Package Weight: 190g / 6.7oz
