This German-made SPL DynaMaxx Model 9735 2-Channel Compressor is a great sounding boutique compressor with some unique features. Maybe the black with blue lightning finish turns some people off, but if you look at the features and specs you’ll see what I mean. It’s a multi-function dynamics toolbox with pristine sound quality.

The unique features include a de-compresser that will restore detail to over-compressed audio, and the specs include a 20 Hz - 100 kHz (-3 dB) frequency response. It also has dedicated push buttons to run it as a soft limiter or as a noise gate, plus a hard bypass along with external side chain connections and “set-and-forget” signal-dependent automation.

This rare unit has a very slight amount of rack rash, but all controls and indicator lights work perfectly, and it sounds fantastic. It comes with its original power cords (US and European), and while I do not still have the printed manual, I do have a PDF of it which I will provide to the buyer.

Please note that I purchase Reverb Safe Shipping with every sale to protect both of us in the event of loss or damage, but your signature will be required upon delivery, and I cannot ship to a P.O. box address.

From the Manufacturer:

The SPL DynaMaxx (Model 9735) is a two-channel analog compressor, limiter, and noise gate known for its "set-and-forget" operation, featuring adaptive time constants, and a unique De-compress function to restore detail in over-compressed audio. Key specifications include an input impedance of 22 kΩ, an output impedance of less than 600 Ω, a frequency response of 20Hz-100kHz (-3dB), and high signal-to-noise ratio of -105 dBu (A-weighted). Its double-VCA drive circuit with THAT 2181 VCAs ensures low distortion, while the 19-inch, 1U rackmount chassis provides a compact design for professional audio environments.

General Specifications:

• Type: 2-channel analog compressor, limiter, noise gate
• Model Number: 9735
• Form Factor: 19-inch, 1U rackmount chassis
• Operation: Set-and-forget with signal-dependent automation of time constants
• Bypass: Relay-controlled hard bypass

Audio Specifications:

• Inputs & Outputs: Instrumentation amplifier, electronically balanced (differential), transformerless
• Nominal Input Level: +6 dB
• Input Impedance: 22 kΩ
• Output Impedance: < 600 Ω
• Max Input Level: +24 dBu
• Max Output Level: +22.4 dBu
• Minimum Load: 600 Ω
• Frequency Response: 20 Hz - 100 kHz (-3 dB)
• THD&N: 0.002% @ 1 kHz
• Signal-to-Noise (A-weighted): -105 dBu

Features:

• Double-VCA Drive: Utilizes two THAT 2181 VCA chips for maximum transparency and low distortion
• De-compress Function: Unique feature to restore vitality to over-compressed audio
• Adaptive Time Constants: Dynamically optimizes attack and release times for each source
• External Side Chain: TRS jack on each channel for external processing
• LED Metering: 20-digit LED ladder meter for gain changes and a Signal LED for input levels above -40dB
• Ground Lift Switch: For power supply noise reduction
