Demon FX King of Drive 2024 - Red

The KING OF DRIVE like new!

Based on ANALOGMAN KING OF TONE OVERDRIVE.
For the money this comes pretty close to my KOT pedals.

There is also a 4 position DIP switch on the inside of the pedal, which you can use to choose between Clean, OD, or DISTORTION mode for each side.I designed this switch to allow almost anyone to be able to find the exact sounds they want in this pedal.
The modes are:
1) Normal Overdrive mode (OD mode):

This is the standard King Of Tone sound, which Jim like
best- a little less drive available than a tube screamer.Factory DIP switch setting has this mode
on the right side. This mode can get about 4 times louder than a tube screamer if desired
2) CLEAN mode : This mode has less distortion, it can be used for clean boosts or clearer, loudersounds. It's sort of a cross between a true clean boost and an overdrive. CLEAN MODE is even
less compressed than the standard OD mode. The factory DIP switch setting uses this mode on
the left channel. This mode can get twice as loud as the OD mode.
3) DISTORTION mode : This mode has more drive than the standard mode- a touch of hard
distortion. The sound is more compressed, yet retains the pedal’s character. This mode can
get almost twice as loud as a tube screamer. Distortion mode is not on either side with the
factory DIP switch setting.
4)add a hi gain switch to choose the high gain and norm model

DIP switch settings
There are 4 DIP switches. Factory setting is
1 2 3 4: ON OFF OFF OFF (up, down, down, down)
The two left switches (1 and 2) are for the RED (right) side.
st nd st
1 switch down=clean, up=OD. 2 switch is for DIST mode when up. When the DIST switch is up, the position of the 1 switch does not matter
much but best if you turn it OFF for more clarity.
The 2 switches on the right side are for the YELLOW side, and work just like the Red side
(#3 = CLEAN or OD, #4=DIST if UP).
The factory setting ON OFF OFF OFF sets the RED (right) channel to OD and Yellow (left) to CLEAN, so you can decide if you like one sound best
, or would like to have both available. If you want both available, leave switches in this setting. To set both channels to be OD mode (CLEAN modwill not be available) then set switches to: ON OFF ON OFF. To set both channels to CLEAN mode (OD not available), set to: OFF OFF OFF OFF.
It is best to have the right (red) side to be the more distorted side, as it comes before the left (yellow) side and will allow the left side to do moreboosting that way. Running a clean boost before an OD will add distortion but not much volume. Running a clean boost after an OD will add
more volume without changing the distortion much. So you can use it either way you like.
