Electro-Voice EKX-15 Passive 2-Way 15" 400-Watt Speaker
This seller has not set a shipping cost for Norway. Please contact them to ask about shipping.
14-Day Return Policy
Enjoy peace of mind with your new gear
Our users rate Reverb
- EKX-15: 1600W (peak), 132 dB peak SPL utilizing high-sensitivity transducers designed and engineered by EV
- EV-patented Signal Synchronized Transducers (SST) waveguide design provides precise and consistent coverage
- Lightweight, compact 15-mm wood enclosure with internal bracing, and durable EVCoat finish
- 8 M10 threaded mounting points, aluminum pole mounts, and all-metal handles
- 90° x 60° pattern for best coverage on mid-size stages. 40° monitor angle with rubber feet
- Single-knob Quicksmart DSP control with LCD display
- Application and location presets
Add to Quote
The EKX-15 15” passive speaker combines quality and reliability in a compact package suitable for a wide range of sound reinforcement scenarios. Ideal for musicians, DJs and live performance, and installed sound applications, the innovative EKX-15 is equipped with features that optimize performance and versatility, including EV-engineered speaker and amplifier components and on-board signal processing with user-friendly single-knob control and application presets for easy set-up. Electro-Voice’s award-winning industrial design – incorporating robust wood enclosures, premium-quality hardware, and durable EVCoat finish – ensures that EKX speakers look as great as they sound.
- Frequency Range (-10 dB)50 Hz - 20 kkHz (Full Space Measurement)
- Suspension8x M10 threaded mounting points
- Minimum Impedance7.2Ω
- HF TransducerDH-1M 1-inch titanium compression driver
- Speaker TypeFull-Range, two way
- Woofer Size15 inches
- Powered or PassivePassive
- Frequency Response (-3 dB)75 Hz - 18 kHz (Full Space Measurement)
- Max. SPL/1m (calc)²132dB
- Coverage (Nominal -6 dB) H90°
- LF TransducerEVS-15M 381 mm (15 in)
- Coverage (Nominal -6 dB) V60°
- Power Rating1600W
- Crossover Frequency1.6 kHz
- Connector TypeDual NL4
- Enclosure Material15 mm, plywood with EVCoat
- Grille18 AWG steel with powdercoat
- Dimensions (HxWxD)26.97" x 17.01" x 16.89"
- Recommended High-Pass Frequency50Hz
- Weight Net51.15lbs (23.2kg)
- FamilyEKX
- Nominal Impedance8Ω
- Axial Sensitivity (SPL, 1 W @ 1 m)96dB (Full Space Measurement)
- Power Handling (Continuous / Peak)400 W/1600W
- Maximum SPL132dB (Maximum SPL is measured at 1 m using broadband pink noise at rated peak power rating)
- Passive Power Handling1600W peak
