Freshly inspected and set up in-house by our esteemed Guitar Tech.  In Very Good Vintage condition with normal wear for an instrument of this age, including scratches, dings, nicks, and natural aging of parts and finish.  All of the fingerboard inlays are original but some have been reglued.  Includes an original Wah effect module.

Electra MPC guitars were made in Japan by Matsumoku for St. Louis Music and became popular partly due to endorsements by artists like Peter Frampton, Leslie West, Rick Derringer, and The Outlaws. Originally, the guitars had Gibson-style headstocks but were changed to a distinctive "wave" headstock shape to avoid legal issues.

The 1970s Electra MPC (Modular Powered Circuits) guitars were innovative electric guitars introduced by Electra in 1976. These guitars featured a pair of cartridge slots built into the guitar cavity that allowed two effect modules to be plugged in and controlled directly from the guitar, eliminating the need for external effect pedals.

Electra manufactured MPC modules with various effects like Phase Shifter, Dynamic Fuzz, Treble & Bass Expander, Overdrive, Auto Wah, Tube Sound, Octave Box, Flanger, and Compressor, plus a special "Mini Amp" headphone amplifier module. The effects are controlled via on/off toggle switches and adjustable knobs on the guitar itself.  Only two effects modules can be plugged in at any given time.  This particular guitar comes with only one effect which is Auto Wah.  Additional modules may be available in the vintage marketplace.

The guitar also has a 5-way rotary selector switch  on the upper bout which operates as follows:

1. Both pickups in series & in phase

2. Bass pickup only for rhythm

3. Both pickups in parallel & in phase

4. Treble pickup only for leads

5. Both pickups in series & out of phase

See below for more details and specifications.

SPECIFICATIONS:

Nickel Hardware

Original Electra Tuners

1 11/16” Plastic Nut

Maple Neck with 24 3/4” Scale Length

Neck Thickness .80" at First Fret and .98" at Twelfth Fret

Rosewood Fingerboard with Acrylic Block Inlays and 12" Radius

22 Medium Frets in Very Good Condition

Original Humbucking Pickups with Built-In Auto Wah Effect

5-Way Rotary Switch Controls Pickup Selection and Wiring Options

Tune-o-Matic Style Bridge with Stop Bar Tailpiece

Flame Maple Veneer Top on Mahogany Body in Cherry Sunburst Finish

Weight 8 lb 2 oz

Newer Gig Bag

Serial Number Not Legible
