Vintage Jackson USA RR1 Rhoads Student Model Diablo Resto-Mod in Black with Gold Pinstripes and Faded Snakeskin Bevels By Mike Learn made in 1983 with Original Hard Shell Case. This guitar features a solid poplar body, maple neck-thru and rosewood fingerboard. Re-equipped with a custom set of aged gold covered Bare Knuckle Handwound pickups, a Cold Sweat humbucker in the neck position and a Bare Knuckle Painkillers in the middle/bridge positions. Controlled by neck/middle/bridge volume pots with push/pull coil splits and a 3-Way toggle switch. The 25.5" scale length neck has mother of pearl dot inlays, white side markers with 22 jumbo frets on a 16" radius with a speed neck profile. The hardware is comprised of black Jackson sealed die-cast tuning machines with cloche heads, a bone nut, a NOS PCS brass Tune-o-matic bridge w/ strings thru body gold tail piece and black knurled dome knobs with a gold pickguard.

This guitar started its life as an original USA RR1 Student model. When it came to us initially it had been previously modified with a Kahler and middle pickup route. We decided to bring this back to its original state while embracing the unique 3-pickup setup with a few tweaks. With some help from our connections, we sourced an NOS original bridge & tailpiece, had Bareknuckle make us a custom set of aged gold pickups and sent the body off to Mike Learn for a full Refin. Before Starting the refin he striped the paint and puzzle pieced a piece of maple into the kahler route. Then to some vintage inspired graphics with classic pinstripes with unique faded gold snake skin bevels. Once Finished this Guitar spent the last few years with one of the biggest jackson collectors in the country before making it's way back to us!

This guitar is in overall good condition. There are some scuffs on the back of the neck near the headstock and around the 12th fret. The body has some light surface marks throughout and there are some small dings and scuffs around the points. The gold hardware has lightly oxidized over time and the new gold parts were aged to match. There are some light finish separation spots on the neck and headstock. The top fins point has a small chip at the front tip. One case latch is broken. (See pics)

Guitar is freshly setup and restrung with 9-42 strings. Includes Original Hard Shell Case.

Specs

• Brand: Jackson
• Model: USA RR1 RHoads Student Model Diablo Resto-Mod
• Year: 1983
• Finish Type: Polyurethane
• Finish: Black with Gold Pinstripes and Faded Snakeskin Bevels
• Painter: Mike Learn
• Country: The USA
• Serial: RR0056
• Condition: Very Good
• Weight: 7lbs 13oz
• Body Type: Solid
• Body Wood: Poplar
• Scale Length: 25.5"
• Neck Joint: Neck Through
• Neck Wood: Quartersawn Maple
• Neck Finish: Gloss Matching
• Finger Board: Rosewood
• Neck Radius: 16"
• Neck Profile: Speed
• Neck Thickness@ 1st Fret: .866"
• Neck Thickness@ 12th Fret: .924"
• Inlays: Mother of Pearl Dot
• Side Markers: White
• Nut: Bone
• Nut Width: 1 11/16"
• Frets: 22 Jumbo
• Pickup Config: HH
• Neck Pickup: Bare Knuckle Cold Sweat w/Aged Gold Cover and Black Bolts
• Middle Pickup: Bare Knuckle Painkiller w/Aged Gold No Holes Cover
• Bridge Pickup: Bare Knuckle Painkiller w/Aged Gold Cover and Black Bolts
• Switch Arrangement: 3-Way Toggle Switch
• Pot Arrangement: 1-Neck Volume, 1-Middle Volume and 1-Bridge Volume
• Coil Tap: Push/Pull Volume Knobs
• Hardware: Black/Aged Gold
• Pickguard: Gold
• Tuning Machines: Jackson Sealed Die-Cast with Cloche heads
• Strap Buttons: Oversized 17mm
• Bridge: Jackson PCS Tune-o-matic w/ Strings Thru Body
• Knobs: Black Knurled Dome
• Mod: Diablo Mod Shop Edition, Refin, Refret, Bone Nut, Pickups, Vintage NOS old stock bridge and tail piece, Refin, pots/wiring, Mike Learn Truss Rod Cover
• String Gauge: 9-42
• Case: Original Hard Shell Case


Condition

Overall Condition: ★★★★ ·
Body Front: ★★★★✯
Body Back: ★★★★✯
Body Sides: ★★★★✯
Fret Board: ★★★★ ·
Frets: ★★★★ ·
Neck Back: ★★★★✯
Headstock Front: ★★★★✯
Headstock Back: ★★★★✯
Headstock Sides: ★★★★★
Hardware: ★★★★✯
Pickups: ★★★★ ·
Bridge: ★★★★ ·
Knobs: ★★★★✯
Pickguard: ★★★★ ·
