As evidenced by its long-standing association with such giants of jazz guitar as George Benson, Pat Metheny, and John Scofield, Ibanez has been a constant pioneer in the world of hollow-body guitar building for more than three decades. Part of that legacy is owed to the Artcore collection, which has succeeded in smashing any and all preconceptions in its wake as to what a great hollow or semi-hollow ought to be. The Artcore formula builds on equal parts luthiery know-how, daring design, and a passion for warm, full-bodied tone.

The AF55 features a full hollow body, a set-in neck and Laurel fingerboard to create the warm-sounding characteristics of the AF55. Ibanez designed the Infinity R pickups to give you big, full tone and well-balanced output.

SPEC
neck type: AF Artcore Nyatoh Set-in neck
top/back/side: Linden Top/Back/Sides
fretboard: Bound Laurel fretboard/White dot inlay
fret: Medium frets
number of frets: 20
bridge: Gibraltar Performer
string space: 10.5mm
tailpiece: VT06
neck pickup: Infinity R (H) neck pickup (Passive/Ceramic)
bridge pickup: Infinity R (H) bridge pickup (Passive/Ceramic)
factory tuning: 1E,2B,3G,4D,5A,6E
string gauge: .010/.013/.017/.030/.042/.052
nut: Plastic
hardware color: Chrome

NECK DIMENSIONS

Scale : 628mm/24.7"
a : Width: 43mm at NUT
b : Width: 56.3mm at 20F
c : Thickness: 21mm at 1F
d : Thickness: 24mm at 9F
Radius : 305mmR

BODY DIMENSIONS

• a : Length19 1/2"
• b : Width15 3/4"
• c : Max Depth3 5/8"

Includes Free Pro Set-up: Munro Music's guitar staff promises the highest quality in guitar playability. Our guitar techs will tweak every neck to maximize playing comfort, adjust the string height for playability, and correct final tuning stability with an intonation adjustment.  Every guitar we sell includes the following:

• neck adjustment
• string height adjustment
• intonation adjustment
