The Roland JX-8P is a 61-key, six-voice polyphonic analog synthesizer released in 1985, notable for its hybrid analog-digital architecture. Below is an overview of its key features and its use in studios, by producers, and in notable songs and albums, based on available information.

Key Features and Specifications

• Architecture: The JX-8P features two digitally controlled oscillators (DCOs) per voice, offering sawtooth, square, pulse, and noise waveforms. It includes cross-modulation, oscillator sync, and a high-pass/low-pass filter combination for versatile sound design.
• Polyphony and Modes: It provides six-voice polyphony with two polyphonic modes, two unison modes, and two solo modes (one stacking all oscillators for a monophonic sound).
• Chorus Effect: A signature Roland stereo chorus adds depth, ideal for lush pads and strings.
• Envelopes and Modulation: Two software-generated ADSR envelopes (for VCA and VCF) are slightly soft, making it suited for smooth textures rather than aggressive sounds. It includes an LFO for modulation but lacks pulse width modulation (PWM).
• MIDI and Programming: Advanced MIDI implementation for its era, with system-exclusive (sysex) support for external control. Programming is done via a single “edit” slider and membrane buttons, though the optional PG-800 programmer provides hands-on sliders for easier editing. Tablets can now emulate the PG-800.
• Memory: Stores 64 preset patches (two banks of 32), 32 user patches internally, and 32 additional patches via the optional M-16C cartridge.
• Keyboard: Velocity- and aftertouch-sensitive, with controls for vibrato, brilliance, and volume via aftertouch.
• Portability and Design: Weighs 11.5 kg, with stereo/mono outputs, headphone jack, MIDI connectors, and a portamento feature.

The JX-8P was marketed as blending analog warmth with digital precision, capable of classic analog sounds and FM-like metallic tones, competing with the Yamaha DX7. Its lack of onboard knobs makes it less intuitive for live tweaking without the PG-800, but its sound quality and MIDI capabilities made it a studio favorite.

Use in Studios and by Producers

The JX-8P was widely adopted in the mid-1980s for its rich, polished sound, fitting the era’s synth-pop and new wave aesthetics. Notable users and contexts include:

• Jean-Michel Jarre: Listed the JX-8P among instruments used for his 1986 album Rendez-Vous.
• Trevor Horn: Praised the JX-8P in a Roland interview, noting his fondness for its sound.
• Stock Aitken Waterman: The production trio used the JX-8P for their hit factory pop productions in the late 1980s.
• Kate Bush’s Band: Used the JX-8P with the PG-800 during a 1987 performance of “Running Up That Hill” for The Secret Policeman’s Third Ball, alongside David Gilmour.
• Kebu: Featured the JX-8P in his synthesizer setup, as noted in an Iheartsynths interview.
• Leftfield: Showcased the JX-8P in a Facebook post about their studio gear.
• Roger (The Cure): Played the JX-8P while touring with The Cure.
• Nemo Studio (1986): A Roland JX-8P was photographed in this studio, indicating its presence in professional recording environments.
• General Use: Favored by artists like Depeche Mode, Go West, The Human League, Vangelis, and Devo for its versatility in studio and live settings.

Songs and Albums Featuring the JX-8P

The JX-8P’s distinctive sound, particularly its brass patches, pads, and chorused strings, appeared in several iconic tracks and albums:

• Europe – “The Final Countdown” (1986): The song’s famous opening synth fanfare was created using a JX-8P brass patch programmed by Joey Tempest, layered with a Yamaha DX7 preset. This is one of the most recognizable uses of the JX-8P.
• Jean-Michel Jarre – Rendez-Vous (1986): The JX-8P is explicitly credited in the album’s liner notes, used alongside instruments like the ARP 2600 and Fairlight.
• Gloria Estefan – “Rhythm Is Gonna Get You” (1988): A synth pad sound, believed to be from the JX-8P, appears prominently at 1:19–1:29 and throughout the track.
• Change – “Mutual Attraction” (1985): Features a prominent JX-8P synth pad sound, though the exact preset is unclear due to possible custom tweaks. Some suggest it resembles Internal 12 “Touch Ow,” but this may be a custom patch.
• Go West: A song (unspecified) is noted to use a sound close to JX-8P preset I:12, though effects or post-processing may alter the exact match.
• Van Halen – “Jump” (1984): Speculated to use a JX-8P patch, possibly an “OB” preset, though not definitively confirmed.

Additional Notes

• Sound Characteristics: The JX-8P excels at warm, evolving pads, brass, and FM-like percussive sounds, enhanced by its chorus effect. It’s less suited for punchy or aggressive tones due to slower envelopes but shines in layered mixes, often sitting “reserved” in the background.
• Modern Relevance: Its sound has been emulated in Roland’s JX-08 Boutique, ZEN-Core Model Expansion, and JUPITER-Xm, with expanded polyphony and built-in PG-800-style controls.
• Challenges: Users note the tedious programming without a PG-800 and the synth’s weight (11.5 kg) as drawbacks for gigging. Mods like the Kiwi mod add extra modulation options, enhancing its capabilities.

Conclusion

The Roland JX-8P is celebrated for its lush, versatile sound, bridging analog warmth and digital precision. Its adoption by prominent artists and studios in the 1980s, coupled with its presence in iconic tracks like “The Final Countdown” and albums like Rendez-Vous, underscores its lasting impact. While programming can be cumbersome without the PG-800, its rich tones and MIDI capabilities make it a beloved tool for producers and musicians, both in its original form and modern emulations.

100V version

Import tax

・ Import duties, taxes, and other charges which are not included in the item price or shipping charges are the buyer's responsibility.

・ Please check with your country's customs office to determine what these additional costs will be prior to bidding or buying.
Let me know what you think afterwards. more test video on DB Studio TV yotube channel
