** Brand New ,Sealed!!

** Contact for pickup time or shipping quotation

Features:

Max Polyphony: 2 Voices duophonic, normally monophonic

VCO-1: Voltage Control Oscillator 1

Waveforms: Sawtooth, Square

Frequency Range: Approx. 0.03Hz - 30Hz (LFO mode), approx. 10Hz - 10kHz (audio mode)

Voltage Control Response: 1V/Octave

VCO-2: Voltage Control Oscillator 2

Waveforms: Sawtooth, Pulse (dynamic pulse), Triangle, Sine

Frequency Range Covered: Approx. 0.3Hz - 30Hz (LFO mode), approx. 10Hz - 10kHz (audio mode)

Pulse Width: 10% - 90%

Voltage Control Response: 1V/Octave

VCO-3: Voltage Control Oscillator 3

Shapes waveform: Sawtooth, pulse (dynamic pulse)

Frequency range covered: Approx. 0.3Hz - 30Hz (LFO mode), approx. 10Hz - 10kHz (audio mode)

Pulse width: 10% - 90%

Voltage control response: 1V/Octave

VCF: Voltage Controlled Filter

Low-pass: Type 1 (early 24dB/oct), Type 2 (late 24dB/oct)

Frequency range: 10Hz - 10kHz

Resonance: 1/2 with self-oscillation

VCA: Voltage Controlled Amplifier

Control voltage: AR and ADSR (already connected internally)

White or pink noise generator

Ring Modulator: Analog multiplier

Input signal (already connected internally): VCO-1 Sawtooth, VCO-2 Sine

Sampled Signal: Noise (already connected internally)

Audio Outputs: Jack (left, right)

Connector: 3.5mm mono Jack

Output level (max): +9dBu @ 10kOhm

Output impedance: 1.2kOhm

Connector: XLR

Output level (max): +4dBu @ 600 Ohm load

Output impedance: 20kOhm

Headphone output: 6.3mm stereo Jack

Output level (max): 50mW + 50mW @ 33 Ohm

Output impedance: 20 Ohm

Preamp input for external sources: 3.5mm Jack

Maximum input level: -10dBu

Input impedance: 100kOhm

MIDI connectors: In, Out, Thru

USB port: USB-B

Keyboard: 49 notes with aftertouch, not velocity sensitive

Upper Voice output -3 V -/+10V, 1 V/Oct

Lower Voice Output -3V -/+ 7V, 1V/Oct

LFO Output: Delta ±5V, 10Vp-p, Square +10V, 10Vp-p

Delayed sine wave: ±3V, 6Vp-p

External vibrato: Input voltage ±10V max

Slider Vibrato Depth: 1 Octave max

Slider Vibrato Delay: 0 - 2.5sec

LFO Speed ​​slider: 0.25 - 25Hz

Pitch Bend Control: ±1 Octave

Transpose switch: ±2 Octave

Slider Portamento Speed: Approx. 0.25 msec/Oct (max)

Minimum speed: 0.5 sec/Oct (max)

Portamento Pedal: Korg PS-1/PS-3

Interval Pedal: Korg PS-1/PS-3

Gain Output Voltage (on panel): 0V at all keys up, +10V at key on

Trigger Output Voltage (panel): +10V, 0.5ms pulse wave at key press

Arpeggiator: Off, Auto, Up, Down, Up&Down, Random, Seq Play

Power Consumption: 30W

ARP 2600 FS Dimensions: 836 x 232 x 509mm

Weight: 19.3kg

ARP 3620 Keyboard Dimensions: 914 x 274 x 158mm

Weight: 11.3kg

Included Accessories: Road case, power cable, 8-pin DIN cable, mini-phone cable

Optional Accessories: Korg PS1/PS3
