***ON SALE*** Powersoft Litemod 4HC / DSPLITE / Medium Heatsink 2024

Fully Assembled AMP , DSP, Heatsink. Initialized and ready to program in Armonia.

Emmersive is the Official OEM distributor for Powersoft OEM plate amps and DSP.

LiteMod 4HC is an extremely versatile amplification platform integrating PFC equipped power supply for universal mains operation and 4 output stages delivering up to 2400W total.

LiteMod 4HC boosts flexibility, being configurable as four, three, two channels, or single high power output channel and supporting 2Ω operation. It can be used in high channel count applications, three way and two way designs, subwoofer + satellite systems.

The pristine sonic performance is obtained in conjunction with the ease of use, in a compact solution.

Compatible with the majority of DSP solutions available from Powersoft, the LiteMod 4HC performances can be easily tailored and controlled through Powersoft’s ArmoníaPlus making all kind of processing tools easily available.

MyPowersoft services are available for this product

Output powerSingle-Ended Mode (SE)750 W @ 4 ΩBridge Mode (BTL)1400 W @ 8 Ω800 W @ 16 ΩParallel Mode (PTL)1400 W @ 2 ΩParallel Bridged Mode (PBTL)2400 W @ 4 ΩMax output voltage / currentSingle-Ended Mode (SE)78 Vpeak / 30 ApeakBridge Mode (BTL)156 Vpeak / 30 ApeakParallel Mode (PTL)78 Vpeak / 60 ApeakParallel Bridged Mode (PBTL)156 Vpeak / 60 Apeak

DSPLITE

Compatible with both LiteMod and DigiMod PFC Series amp modules, the DSP-Lite E is a 1-2-in/3-out processing board designed to offer powerful programming capabilities and giving designers and end-users fast and easy control in any OEM application.

The DSP-Lite E is a DSP processing board based on the Analog Devices SigmaDSP® platform, designed to control LiteMod and DigiMod PFC Series amplifier modules, creating OEM amplifier systems.

The DSP-Lite is available in 1 in / 3 out and 2 in / 3 out versions.

The DSP-Lite E features a built-in Ethernet port to offer easy access to DSP-Lite’s powerful programming functionalities directly from a PC using the Powersoft ArmoníaPlus software — giving designers and end-users the ability to control and monitor active loudspeakers, plus quick access to parameter settings, preset banks management, and group control. As with all Powersoft DSP solutions, the DSP-Lite E is also fully compatible with the Powersoft Integration Kit platform.
