Kramer VS-84HN - 8x4 HDMI Matrix Switcher

Kramer VS-84HN - 8x4 HDMI Matrix Switcher - New in Box

The VS−84HN is a high−performance matrix switcher for HDMI signals. It reclocks and equalizes the signal and can route any input to any or all outputs simultaneously.

•  Max. Data Rate — 6.75Gbps (2.25Gbps per graphic channel).
•  HDTV Compatible.
•  HDCP Compliant.
•  HDMI Support — Deep Color, x.v.Color™, Dolby® TrueHD, Dolby Digital Plus, DTS–HD®, and linear PCM 7.1 surround sound.
•  3D Pass–Through.
•  Kramer Equalization & re‑Klocking™ Technology — Rebuilds the digital signal to travel longer distances.
•  EDID Capture — Copies and stores the EDID from a display device.
•  Output Disconnect — Each output.
•  Front Panel Control Lockout.
•  Memory Locations — Stores multiple switches as presets to be recalled and executed when needed.
•  Flexible Control Options — Front panel, IR remote, RS–232 (K–Router Plus™ Windows®–based software is included), Ethernet (Windows®–based Ethernet Configuration Manager & Virtual Serial Port Manager is included).
•  Worldwide Power Supply — 100–240V AC.
•  Standard 19” Rack Mount Size — 1U. Rack "ears" included.

INPUTS: 8 HDMI connectors

OUTPUTS: 4 HDMI connectors

MAX. DATA RATE: 6.75Gbps (2.25Gbps per graphic channel)

COMPLIANCE WITH HDMI STANDARD: HDMI and HDCP

RESOLUTION: Up to UXGA, 1080p

POWER CONSUMPTION: 100–240V AC, 50/60Hz, 40VA

CONTROLS: Front panel buttons, infrared remote control transmitter, RS–232, Ethernet

OPERATING TEMPERATURE: 0° to +40°C (32° to 104°F)

STORAGE TEMPERATURE: –40° to +70°C (–40° to 158°F)

HUMIDITY: 10% to 90%, RHL non–condensing

INCLUDED ACCESSORIES: Power cord, IR transmitter, rack ”ears”

Product Dimensions: 19" x 17.18 x 1U (43.6cm x 43.64cm x 4.36cm) W, D, H
