HK Audio LINEAR-5-MK2-112-XA 1200W 12" Multi-Function Active Speaker

Overview

The HK Audio LINEAR-5-MK2-112-XA is a compact yet powerful 12" active speaker, designed for versatile use in live performances, installations, and events. With its 1200W peak Class D amplifier, it delivers exceptional sound clarity and punch. The 12" woofer with a 2.5" voice coil ensures powerful bass, while the 1" high-frequency driver with a 1.7" voice coil produces crisp highs. This speaker offers a flexible multifunctional design, making it ideal for use as a stage monitor or a full-range PA speaker. The rotatable CD horn (80° x 60°) allows for precise sound dispersion, adapting to any setup configuration.

Features:

• 1200W peak power with Class D bi-amplification
• 12" low/mid speaker with a 2.5" voice coil
• 1" HF driver with a 1.7" voice coil
• Rotatable 80° x 60° CD horn for optimal dispersion
• Maximum SPL: 136 dB
• Frequency range: 67 Hz - 19 kHz
• Advanced DSP with parametric EQ and filter presets
• Durable wooden housing with a hybrid design for portability
• Multiple input/output options: XLR combo input, DSP output, and network control

Specifications:

• Power Output: 1200W peak
• Frequency Response: 67 Hz - 19 kHz (-10 dB)
• Max SPL: 136 dB
• Dimensions: 23.2" x 14.1" x 12" (59 cm x 36 cm x 30.5 cm)
• Weight: 38.8 lbs (17.6 kg)
• Mounting: M8 rigging points, 35 mm pole mount
